DANAHER MOTION M.1016.9544 Input Module

Technical SpecificationsModel：M.1016.9544 Brand：DANAHER MOTION (Giddings & Lewis) Product Type: PIC900 rack-mounted isolated digital input module for CNC motion control system

Module Feature:Channel:32 isolated digital input points Input signal:24VDC sink/source compatible Opto-isolation between field signal and control backplane Per-channel status LED for quick fault diagnosis Filter circuit for suppressing field electrical noise Supports hot-swap operation in qualified PIC900 rack configuration

Electrical Parameters:Backplane supply:24VDC from PIC900 rack power Field input voltage range:18~30VDC Input impedance:High impedance for signal stability Galvanic isolation voltage:500V between field and logic side

Mechanical & Structure:Housing:Metal shielded rack module Mounting:Plug-in installation for PIC900 backplane rack Protection class:IP20

Environmental:Operating temperature:0℃ ~ +50℃ Ambient humidity:5~85% non-condensing Certification:UL, CE approved Status:Manufacturer discontinued legacy spare part

System compatibility

M.1016.9544 belongs to DANAHER MOTION Giddings & Lewis PIC900 I/O series. Compatible with PIC900 controller rack, DSM Centurion servo drives. Widely applied on heavy-duty CNC lathes, milling and boring machine tools for limit switch, proximity sensor and button signal acquisition.

Function

M.1016.9544 is 32-channel opto-isolated digital input module manufactured by DANAHER MOTION Giddings & Lewis. It collects digital signals from field sensors, limit switches and operator push buttons, then transmits signal status to PIC900 controller through rack backplane. Optical isolation protects CNC main logic from surge and noise coming from machine field wiring. Each LED indicates real-time signal state of corresponding input channel.

Installation

Follow lockout/tagout safety procedure before installation. Cut off power of PIC900 rack. Insert M.1016.9544 into empty rack slot and lock module handle. Connect field sensor wiring to terminal block according to Giddings & Lewis PIC900 hardware manual. After wiring, power up and test each input point.

Interface

PIC900 backplane connector, field signal terminal block, channel status LED indicator for DANAHER MOTION M.1016.9544.

Feature

Original DANAHER MOTION M.1016.9544 32-channel isolated input module,24VDC field input,opto-coupler isolation,per-channel LED diagnostic,rack plug-in design,anti-interference filter circuit,UL & CE certified. This spare unit is used for CNC machine I/O expansion, signal acquisition and system maintenance replacement.

Diagnostic

No input signal: Check 24VDC field power, sensor wiring and input channel status in controller software. Fluctuating signal: Inspect grounding, cable shielding and interference from surrounding power circuit. Module offline: Verify backplane connection, rack power supply and slot address setting.

Product Brief

M.1016.9544 is DANAHER MOTION Giddings & Lewis PIC900 32-channel opto-isolated digital input module,24VDC field signal acquisition,classic rack mount spare part for heavy-duty CNC machine control system.
