DANAHER MOTION M.1017.4236 Analog Input Module

Technical SpecificationsModel：M.1017.4236 Brand：DANAHER MOTION (Giddings & Lewis) Product Type: PIC900 rack-mounted isolated analog input module for CNC motion control system

Module Feature:Channel:8 isolated analog input points Signal type:Voltage ±10V, current 4~20mA configurable per channel High resolution A/D conversion, built-in digital filter for noise suppression Galvanic isolation between field side and backplane control logic Per-channel status LED for signal diagnostic Supports hot-swap under qualified PIC900 rack configuration

Electrical Parameters:Backplane supply:24VDC from PIC900 rack power Field signal:±10VDC / 4~20mA, software selectable Isolation voltage:500V between field circuit and control logic

Mechanical & Structure:Housing:Metal shielded rack module Mounting:Plug-in installation for PIC900 backplane rack Protection class:IP20

Environmental:Operating temperature:0℃ ~ +50℃ Ambient humidity:5~85% non-condensing Certification:UL, CE approved Status:Manufacturer discontinued legacy spare part

System compatibility

M.1017.4236 belongs to DANAHER MOTION Giddings & Lewis PIC900 analog I/O series. Compatible with PIC900 controller rack and Centurion DSM servo drives. Widely used for heavy CNC machine pressure, temperature and transducer analog signal collection.

Function

M.1017.4236 is 8-channel opto-isolated analog input module manufactured by DANAHER MOTION Giddings & Lewis. It receives analog signals from pressure transducers, temperature sensors and other field analog devices, converts analog signals to digital data via high precision ADC and transmits data to PIC900 controller through rack backplane. Galvanic isolation protects CNC control logic from field surge and electrical noise.

Installation

Follow lockout/tagout safety procedure before installation. Cut off power of PIC900 rack. Insert M.1017.4236 into empty rack slot and lock module handle. Connect field analog sensor wiring to terminal connector according to Giddings & Lewis PIC900 hardware manual. Power up and calibrate each analog channel during commissioning.

Interface

PIC900 backplane connector, analog field signal terminal block, channel status LED indicator for DANAHER MOTION M.1017.4236.

Feature

Original DANAHER MOTION M.1017.4236 8-channel isolated analog input module,±10V /4-20mA configurable,high precision ADC,built-in digital filter,rack plug-in design,UL & CE certified. This spare unit is used for CNC machine analog signal acquisition,system expansion and maintenance replacement.

Diagnostic

No analog reading: Check field sensor power, wiring and channel configuration in controller software. Unstable fluctuating reading: Inspect shielding cable, grounding and electromagnetic interference. Module offline: Verify backplane connection, rack 24V power and slot address setting.

Product Brief

M.1017.4236 is DANAHER MOTION Giddings & Lewis PIC900 8-channel isolated analog input module,supports voltage and current signal acquisition,classic rack mount spare part for heavy-duty CNC machine control system.
