DELEM 7441-002/1 HSB Bus Communication Cable

Technical Specifications

Model: 7441-002/1 Brand: DELEM (Netherlands) Product Type: HSB fieldbus communication cable Mounting: Wiring inside press brake electrical cabinet Operating temperature: 0℃ ~ +70℃ Storage temperature: -20℃ ~ +80℃ Relative humidity: 5%~95%, non-condensing Protection: Shielded cable, anti-interference Weight: 0.25 kg

System compatibility

7441-002/1 is dedicated HSB bus cable for DELEM Modusys system. It connects DA series controller and DM series axis control modules, compatible with DA51,DA52,DA53,DA56,DA61,DA65 and DM51,DM52 modules, widely used for electro-hydraulic synchronous press brake maintenance and retrofit.

Function

7441-002/1 transmits high-speed real-time position and control signals between CNC controller and axis modules. It realizes synchronous data exchange for multi-axis motion control, transfers encoder feedback data and hydraulic valve control commands. The shielded structure suppresses electromagnetic interference from hydraulic valves and power circuit. It is used to replace damaged communication cable when the system reports HSB bus error, axis sync failure or intermittent communication dropout.

Installation

Cut off main power supply before wiring. Route the cable separately from high-power power lines, avoid parallel laying with hydraulic valve power cables. Connect both ends to HSB bus terminals, install terminal resistor at the end of bus line, fix cable with cable clips, complete grounding for shielding layer. Power on and perform bus communication test before formal production.

Interface

Dedicated HSB bus plug connectors at both ends, multi-core twisted pair, copper shielded screen for DELEM 7441-002/1 cable.

Feature

Original DELEM HSB bus cable, twisted pair design, full copper shielding, high noise immunity, stable high-speed real-time data transmission, oil-resistant and abrasion-resistant outer jacket, designed for industrial cabinet environment. This spare part supports maintenance of DELEM electro-hydraulic press brake systems.

Diagnostic

Bus communication alarm: check cable breakage, connector loose or pin oxidation. Random axis sync error: verify shielding grounding, separate cable routing from power lines. No communication: check connector pin definition and bus terminal resistance.

Product Brief

7441-002/1 is Dutch DELEM dedicated HSB shielded bus cable for Modusys system. It delivers high-speed real-time communication between DA controller and DM axis modules, classic spare part for legacy sheet metal bending machine overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
