DELEM DA58 CNC Press Brake Controller

Technical Specifications

Model: DA58 Brand: DELEM (Netherlands) Product Type: CNC Press Brake Controller Mounting: Panel / swing arm mounting on bending machine cabinet Operating temperature: 0℃ ~ +45℃ Storage temperature: -20℃ ~ +70℃ Relative humidity: 5%~95%, non-condensing Protection: IP20 (front panel) Power supply: 24V DC Weight: 5.2 kg

System compatibility

DA58 is a high-performance graphical CNC controller for DELEM hydraulic press brake systems. It communicates with DELEM DM series axis modules via HSB high-speed bus, matched with linear encoders and hydraulic proportional valves. It fits electro-hydraulic synchronous press brakes and tandem bending machines, widely used for sheet metal workshop machine renovation and spare replacement.

Function

DA58 acts as the core operation control unit of hydraulic press brake. It supports 2D graphical part programming, automatic bend sequence calculation and bend simulation with integrated collision detection. It stores large capacity bending programs, tool libraries and material parameters, supports Y1,Y2,X,R,Z multi-axis closed-loop control and automatic crowning compensation. It monitors ram position, bending tonnage and machine running status, triggers alarm once over-travel or hydraulic faults occur. It is used to replace defective controllers when press brake cannot run graphical bending programming.

Installation

Cut off main power supply before installation. Reserve panel cutout on machine cabinet, mount DA58 and lock fixing fasteners. Connect 24V DC power, HSB fieldbus, encoder cables and hydraulic valve signal terminals. Check wiring definition, upload machine parameters, perform axis homing and trial bending test before formal production.

Interface

USB port, RS232 communication port, Ethernet, encoder input ports, digital I/O terminals, integrated valve amplifier interface, LED status indicators for DELEM DA58 controller.

Feature

Original DELEM DA58 graphic controller, 15 inch TFT color display, physical shortcut keyboard, automatic unfolded length calculation, built-in collision check, USB program backup and restore, advanced Y-axis hydraulic control algorithm for open/closed loop hydraulic valves. It supports Profile-T offline programming software and multi-language menu. This legacy spare part supports field repair and upgrade of DELEM electro-hydraulic synchronous press brake systems.

Diagnostic

No display after power on: check 24V DC power supply and power fuse for DA58. Bending sequence calculation error: verify machine parameter configuration and tool library data. Intermittent communication alarm: inspect HSB bus cable, shielding and cabinet grounding condition.

Product Brief

DA58 is Dutch DELEM graphical CNC controller for electro-hydraulic synchronous press brake. It executes 2D graphic programming and multi-axis closed-loop control with bend simulation for sheet metal bending operation, classic spare part for legacy metal fabrication machine overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
