DELEM DM-104 Motion Control Axis Module

Technical Specifications

Model: DM-104 Brand: DELEM (Netherlands) Product Type: Multi-Axis Motion Control Module Mounting: DIN rail mounting inside press brake electrical cabinet Operating temperature: 0℃ ~ +45℃ Storage temperature: -20℃ ~ +70℃ Relative humidity: 5%~95%, non-condensing Protection: IP20 Power supply: 24V DC Weight: 1.2 kg

System compatibility

DM-104 is high-performance four-axis motion control module of DELEM Modusys system. It communicates with DELEM DA series CNC controllers via HSB high-speed fieldbus. Compatible with DA52,DA53,DA56,DA58,DA61,DA65 controllers. It connects multiple linear encoders and hydraulic proportional valves, widely used for multi-axis electro-hydraulic synchronous press brake and tandem bending machine overhaul and spare replacement.

Function

DM-104 performs real-time closed-loop position calculation for up to 4 axes. It receives position feedback signals from linear encoders, computes position deviation and outputs analog control signals to hydraulic proportional valves. It supports Y1,Y2,X,R four-axis synchronous control and crowning compensation signal output. It continuously monitors encoder signal quality, HSB bus communication and power supply status, sends fault alarm messages to main controller once signal loss or axis synchronization error occurs. It is used to replace defective axis modules when press brake loses multi-axis synchronous bending control.

Installation

Cut off main power supply before installation. Mount DM-104 on DIN rail and lock the module. Connect 24V DC power, HSB bus cable, multi-channel encoder cables and hydraulic valve analog terminals. Check wiring definition, upload machine parameters, complete axis homing and test run before formal bending production.

Interface

HSB fieldbus port, four encoder input connectors, multi-channel analog output terminals for hydraulic valves, digital I/O terminals, LED status indicators for DELEM DM-104 module.

Feature

Original DELEM Modusys 4-axis module, high-speed HSB bus real-time communication, high-resolution position sampling, built-in self-diagnostic function, metal housing, strong anti-interference capability. This legacy spare part supports field repair of multi-axis DELEM electro-hydraulic press brake systems.

Diagnostic

No power indicator: check 24V DC power supply and module fuse for DM-104. Multi-axis synchronization deviation: verify encoder wiring, shielding and machine parameter configuration. HSB bus communication error: inspect bus cable connection, terminal resistor and grounding condition.

Product Brief

DM-104 is Dutch DELEM Modusys four-axis motion control module for electro-hydraulic synchronous press brake. It collects multi-channel linear encoder feedback and outputs analog valve signals for multi-axis closed-loop synchronous control, classic spare part for legacy metal fabrication machine overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
