Eaton HND312WK MCCB Unit

Module Feature

HND312WK belongs to Eaton Series C large frame molded case circuit breaker. Rated current 1200A, 3-pole design, rated voltage up to 600VAC. High breaking capacity: 100kA@240VAC,50kA@480VAC,35kA@600VAC. Busbar type terminals, no cable lugs supplied. Adopts thermal-magnetic trip mechanism, provides overload and short-circuit protection. Robust molded insulation housing for heavy duty continuous power distribution. Widely used as main incoming protection for factory power rooms, large control panels and industrial power distribution systems.

Working principle

Bi-metallic thermal element reacts to overload current and triggers delayed trip. Magnetic trip element instantly responds to large short-circuit fault current. Internal mechanical linkage releases contact mechanism to cut off power circuit, protecting downstream cables and electrical equipment.

Onboard components

Molded insulating housing, moving & fixed main contacts, bimetallic thermal trip element, magnetic trip coil, mechanical operating handle, arc extinguishing chamber, busbar connection terminals.

LED indicators

No built-in LED indicators.

Hardware self-diagnosis

Visual inspection of contact surface and arc chamber, test trip function, measure insulation resistance, check tightening torque of busbar connection.

Programming software

No dedicated programming software.

Electrical & Process Parameters

Model:HND312WK Brand:Eaton Device type:Series C HND Frame Molded Case Circuit Breaker Poles:3P Rated current:1200A Rated voltage:600VAC Interrupt rating:35kA@600VAC Trip type:Thermal-magnetic Cooling:Natural convection cooling Protection:Overload, short circuit protection

Mechanical & Structure

Mounting:Panel mount Protection class:IP20 Housing:Thermoset molded insulation housing

Environmental

Operating temperature:-10℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:UL,CSA compliant Status: Eaton original large frame MCCB for industrial main power distribution

Installation

Follow strict high voltage safety procedure before handling.Mount breaker firmly inside power cabinet.Connect incoming and outgoing busbar, apply specified torque to connection bolts.Complete trip test before energizing the main circuit.

Interface

Busbar connection interface, mechanical operation handle.

Diagnostic

Cannot close handle:interlock triggered or internal fault. Trips immediately after power on:short circuit downstream or damaged trip assembly. Overheating at terminals:insufficient bolt torque, loose busbar connection.

Product Brief

Eaton HND312WK Series C 3P 1200A 600V molded case circuit breaker, high interrupt rating, busbar connection, used for main incoming circuit overload and short-circuit protection.
