Emerson 12P1731X082 Thermocouple mV Input Module

Technical Specifications

Model：12P1731X082（Alias:KJ3002X1‑BG2, VE4003S5B1）

Brand：Emerson

Product Type：Thermocouple mV Input Module

Applicable System：Emerson DeltaV DCS system, petrochemical and thermal power plant control cabinet

Supply Voltage：12VDC LocalBus power

Interface：DeltaV rack backplane connector, field thermocouple signal terminal block

Common Revision：Multiple hardware revisions available

Status Indicator：On‑board LED for power supply, channel status and fault diagnostic status

Built‑in Function：Multi‑type thermocouple signal acquisition, mV signal sampling, built‑in CJC cold‑junction compensation, signal isolation filtering, A/D conversion, temperature data upload to DeltaV main controller, channel open‑circuit detection, fault self‑diagnosis

Working Temperature：0℃ ~ +60℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：DeltaV rack slot‑in installation

Weight：0.45kg

Product Brief:

12P1731X082, alias KJ3002X1‑BG2 and VE4003S5B1, is legacy 8‑channel thermocouple mV input module for Emerson DeltaV DCS system. It receives millivolt‑level signals from field thermocouple temperature sensors. Built‑in CJC cold‑junction compensation ensures accurate temperature measurement. After isolation filtering and A/D conversion, temperature process data is transmitted to DeltaV main controller through rack backplane bus. It supports thermocouple wire break/open‑circuit detection. On‑board LED gives visual feedback of power, channel running and fault conditions. This is EOL discontinued spare part,widely used for maintenance and renovation of petrochemical and thermal power plant DeltaV DCS equipment. Please confirm hardware revision and rack compatibility before purchase. Strict ESD anti‑static protection shall be followed during installation and replacement。
