Emerson 1395‑B75‑C3‑P12‑X1 Regenerative Digital DC Drive

Technical Specifications

Model：1395‑B75‑C3‑P12‑X1

Brand：Emerson

Product Type：Regenerative Digital DC Drive

Applicable System：Heavy‑duty industrial DC motor control system, metallurgy, printing, paper‑making production line

Input：3‑Phase 460VAC，50/60Hz

Output：500VDC，75HP(56kW)

Overload capacity：150% FLA for 60s，200% FLA for 10s

Interface：Power wiring terminal,Port A digital reference adapter board,auxiliary contact terminals(1NO+1NC),encoder/tachometer feedback interface

Common Revision：Multiple hardware revisions available

Status Indicator：Front panel LED status & fault diagnostic indicators

Built‑in Function：Microprocessor digital speed regulation，regenerative energy feedback to grid，encoder / DC tachometer speed feedback，DC contactor control，auxiliary signal relay output，over‑current,over‑voltage,over‑temperature protection，fault self‑diagnosis and alarm

Working Temperature：0℃ ~ +55℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP00 open‑chassis design

Mounting：Cabinet floor‑mount installation

Weight：49.9kg

Product Brief:

1395‑B75‑C3‑P12‑X1 is Emerson regenerative digital DC drive unit. It adopts microprocessor digital control architecture, delivers 75HP power for DC motor driving. The regenerative function feeds braking energy back to power grid, which is suitable for frequent start‑stop and large inertia load occasions. Equipped with built‑in DC contactor, Port‑A digital reference adapter board and 1NO+1NC auxiliary contacts. It supports encoder or DC tachometer feedback, realizes high‑precision speed regulation within 1000:1 speed range. Comprehensive protection functions prevent damage caused by over‑current, over‑voltage and over‑temperature. This is EOL discontinued spare part,widely used for maintenance and renovation of metallurgy, printing, paper‑making and other old production lines. Please confirm hardware revision,motor parameters and feedback signal type before purchase. Strict ESD anti‑static protection shall be followed during installation and replacement.
