Emerson 1C31139G03 Ovation Analog Output Personality Module

Technical Specifications

Model：1C31139G03

Brand：Emerson

Product Type：4‑20mA Current Output Personality Module

Applicable System：Emerson Ovation distributed control system thermal power plant DCS control cabinet

Matching Module：1C31132G01 1C31132G02 analog output electronics module

Channel quantity：8 analog output channels

Output signal type：4‑20mA current output

Load resistance：Max 600Ω per channel

Isolation：1000VAC field‑to‑backplane isolation

Installation：Plug‑in install with AO electronic module on Ovation I/O base

Common Revision：G03 hardware revised version

Status Indicator：No independent LED indicator shares status LED of host electronic module

Built‑in Function：Hardware 4‑20mA current output configuration short‑circuit protection surge interference suppression cooperate with host module drive field positioners and control valves

Working Temperature：0℃ ~ +60℃

Storage Temperature：‑40℃ ~ +85℃

Protection Class：IP20

Weight：0.13kg

Product Brief:

1C31139G03 is Emerson Ovation analog output personality module G03 hardware revision works paired with 1C31132 series electronic modules

It is plugged onto I/O base together with host module defines 8‑channel hardware for 4‑20mA current analog output signals

This personality module outputs standard 4‑20mA current signal widely used for boiler control valves positioners and process actuator driving

Max 600Ω load resistance supports long‑distance field wiring for thermal‑process closed‑loop regulation

1000VAC isolation separates field side from DCS logic backplane suppresses ground loop interference and transient surge damage

It converts digital control value from host electronic module into stable 4‑20mA current for field device adjustment

No extra software configuration required after correct physical installation host module identifies personality hardware automatically

Shares hot‑swap open‑load diagnosis and surge suppression features from matched AO electronic module

This is EOL discontinued spare part widely used for maintenance and renovation of thermal power plant Ovation DCS system

Please confirm matching host module model before purchase

Strict ESD anti‑static protection shall be followed during installation and replacement
