Emerson Rosemount 1151DP3E12 Differential Pressure Transmitter

Technical Specifications

Model：1151DP3E12

Brand：Emerson Rosemount

Product Type：Differential Pressure Transmitter

Applicable System：Petrochemical, power, chemical industry, used for tank level, differential pressure and orifice flow measurement

Supply Voltage：12‑45VDC, typical 24VDC

Output Signal：4‑20mA analog signal

Measuring Span：0‑30 inH₂O

Max Static Working Pressure：2000 psi

Process Connection：1/4‑18 NPT

Wetted Material：316 Stainless Steel

Housing Material：Low‑copper cast aluminum alloy

Accuracy：±0.25% FS

Working Temperature：‑40℃ ~ +85℃

Protection Class：IP65

Mounting：2‑inch pipe bracket mounting or direct wall mounting

Weight：2.7kg

Product Brief:

1151DP3E12 is classic analog differential pressure transmitter of Emerson Rosemount 1151 series. It adopts capacitive sensing principle, realizes differential pressure conversion to standard 4‑20mA current signal, widely applied for measuring tank liquid level, orifice plate flow and process differential pressure of liquid, gas and steam media. Aluminum alloy housing provides reliable environmental adaptability for field installation. This model is EOL discontinued product, mainly used for replacement and maintenance of old‑site instruments. Please confirm measuring range, static pressure requirement and process connection before purchase. Strictly follow instrument specification during installation and calibration.
