Fairchild 25-0S0-0-B Precision Pressure Regulator Inquiry Item

Feature & Principle

This regulator adjusts and maintains stable output air pressure by internal diaphragm and valve spool assembly. It compensates for fluctuations of inlet pressure and flow change, provides constant pressure source for positioners, transmitters and other field pneumatic devices.

Specifications

Model: 25-0S0-0-B Brand: Fairchild Series: 25 series Media: Dry compressed air Inlet pressure: Max 250PSI Output range: 0-2PSI Port size: 1/4 NPT Body material: Aluminum alloy Mounting: Panel or bracket mount Certification: CE

Components & Diagnostics

Diaphragm assembly, control spool, adjusting spring, adjustment knob, filter element. Common faults: pressure drift, unable to build pressure, leakage, pressure cannot be adjusted down.

Product Brief

25-0S0-0-B pneumatic regulator, Fairchild instrument spare widely matched with valve positioners and process pneumatic control loops.
