Fisher 49452 Actuator Spare Component

Technical Specifications

Model：49452 Brand：Fisher Product Type: Pneumatic actuator mechanical spare component

Module Feature

Fisher 49452 is precision alloy mechanical spare component for Fisher diaphragm actuator. It forms part of actuator internal force transmission assembly. It features high tensile strength,anti-corrosion and wear-resistant property. Widely used in oil,gas,chemical and power plant globe control valves.

Working principle: Force transmission auxiliary mechanical part Onboard components: Alloy mechanical part, fixing fasteners, sealing washer

LED indicators

Not equipped

Hardware self-diagnosis

Visual inspection, dimensional check, stroke movement test, assembly fit inspection

Programming software

No dedicated software required

Mechanical & Structure

Mounting: Installed inside pneumatic diaphragm actuator Protection class:IP66

Environmental

Operating temperature:-40℃ ~ +120℃ Ambient humidity:5~95% non-condensing Certification:CE Status:Fisher actuator spare part

System compatibility

Compatible with Fisher 657/658 series diaphragm actuator and globe control valve for industrial process control system.

Function

49452 is actuator spare component manufactured by Fisher. It transfers diaphragm thrust to valve stem, ensures stable linear movement during valve stroke. It reduces mechanical clearance and vibration during modulation. It guarantees actuator output thrust and valve positioning repeatability. It is essential spare part for actuator overhaul.

Installation

Follow lockout/tagout safety procedure before installation. Cut off instrument air supply and release residual pressure. Disassemble actuator housing, replace old 49452 component. Check mechanical sliding clearance. Reassemble actuator and perform air tightness test and stroke calibration.

Interface

Actuator internal mounting structure, fixed mounting holes, no LED indicators on 49452.

Diagnostic

Valve stroke unstable: Worn spare component or loose fastener. Actuator output insufficient: Mechanical part deformation. Valve sticking: Increased friction caused by worn component.

Product Brief

49452 Fisher pneumatic diaphragm actuator mechanical spare component,matched with Fisher 657/658 actuator and globe control valve,used for industrial process control valve maintenance,actuator spare part.
