Fisher 7600 Nuclear Globe Control Valve

Technical Specifications

Model：7600 Brand：Fisher Product Type: Nuclear grade globe control valve

Module Feature

Fisher 7600 is nuclear safety grade globe control valve manufactured by Emerson Fisher. It is ASME Section III N stamped certified valve. It adopts heavy-duty valve body, live loaded graphite packing and anti-cavitation valve trim. It has seismic qualification, high temperature and high pressure resistance. Widely applied in nuclear power plant main and auxiliary process loop.

Working principle: Linear stroke fluid throttling for nuclear process medium Onboard components: Cast valve body, valve bonnet, plug/cage trim, live loaded packing, valve stem, flange fasteners

LED indicators

Not equipped

Hardware self-diagnosis

Visual inspection, hydrostatic pressure test, seat leakage test, seismic check, trim wear inspection

Programming software

No dedicated software required

Mechanical & Structure

Mounting: Pipeline flange mounting Protection class:IP66

Environmental

Operating temperature:-40℃ ~ +540℃ Ambient humidity:5~95% non-condensing Certification:ASME N Stamp,CE Status:Fisher nuclear control valve

System compatibility

Matched with Fisher 657/658 series pneumatic diaphragm actuator and digital valve positioner for nuclear power closed-loop control loop.

Function

7600 is nuclear grade globe control valve manufactured by Fisher. It precisely regulates flow, pressure and temperature of process medium in nuclear plant system. Heavy-duty trim design withstands high differential pressure and cavitation. Seismic qualification ensures safe operation under earthquake condition. Live loaded packing reduces fugitive emission. It is key safety valve for nuclear power auxiliary loop.

Installation

Follow lockout/tagout safety procedure before installation. Isolate pipeline and release process pressure. Install valve in correct flow direction, tighten flange bolts crosswise. Mount actuator and positioner, perform stroke test and hydrostatic leakage inspection.

InterfaceFlange pipeline connection, valve stem connected to diaphragm actuator, no LED indicators on 7600.

Diagnostic

Internal leakage: Seat sealing surface erosion or trim damage. Valve sticking: Stem packing over-tightening or trim friction abnormal. External leakage: Packing aging or bonnet flange gasket failure.

Product Brief

7600 Fisher nuclear grade globe control valve,ASME N stamp certified,for nuclear power plant high temperature high pressure process flow regulation,seismic qualified safety control valve.
