Fisher Baumann 24588SVF Pneumatic Control Valve Unit

Feature & Principle

This pneumatic globe control valve receives 4-20mA signal from valve positioner. It drives the valve plug to adjust flow area, realizes continuous closed-loop regulation of liquid or gas flow, pressure and level. It adopts sanitary stainless steel structure, suitable for food, dairy and fine chemical process loops.

Specifications

Model: 24588SVF Brand: Fisher (Baumann) Size: 1 inch Pressure class: CL150 Body material: CF3M / 316 stainless steel Trim: S31600 Cv value: 4.7 Actuator signal: 7~15psi Action type: Linear Connection: Flange Certification: CE

Components & Diagnostics

Pneumatic actuator, valve body, stainless steel trim, valve plug, packing assembly, positioner interface. Common faults: packing leakage, stem jamming, positioner drift, diaphragm aging.

Product Brief

24588SVF control valve, Fisher Baumann flow spare widely used in sanitary, pharmaceutical and industrial fluid regulation systems.
