Fisher RV150X00C22 Cavitrol Hex Retrofit Kit

Technical Specifications

Model：RV150X00C22 Brand：Fisher Product Type: Control valve anti-cavitation retrofit trim kit

Module Feature

Fisher RV150X00C22 is original Cavitrol Hex anti-cavitation retrofit kit for Fisher V150 Vee-Ball rotary control valve. It reduces cavitation, noise and erosion under high pressure drop working condition. The kit includes Cavitrol Hex cartridge, gaskets and installation fasteners. Widely used in oil, gas and chemical high differential pressure pipeline control. Working principle: Multi-stage pressure drop suppression Onboard components: Cavitrol Hex trim cartridge, graphite gasket, alloy fasteners

LED indicators

Not equipped

Hardware self-diagnosis

Visual inspection, dimensional check, pressure drop performance test after installation

Programming software

No dedicated software required

Mechanical & Structure

Mounting: Installed inside V150 valve body Protection class:IP66

Environmental

Operating temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE Status:Fisher Cavitrol Hex valve trim kit

System compatibility

Compatible with Fisher V150 Vee-Ball rotary control valve for high pressure drop industrial process control system.

Function

RV150X00C22 is anti-cavitation trim kit manufactured by Fisher. It adopts multi-stage labyrinth structure to break down fluid pressure step by step, suppress cavitation and reduce valve body erosion and noise. It is used to retrofit existing V150 valve to handle high differential pressure media. It is key spare kit for anti-cavitation process application overhaul.

Installation

Follow lockout/tagout safety procedure before installation. Isolate pipeline and release process pressure. Disassemble valve body, install Cavitrol Hex cartridge and new gasket, tighten fasteners. Restore pipeline pressure and run leakage test and flow performance inspection.

Interface

Valve body internal fitting, fixed mounting holes, no LED indicators on RV150X00C22.

Diagnostic

Serious cavitation noise: Trim damage or incorrect size selection. Internal leakage: Gasket damage or improper tightening. Erosion on valve body: Cavitation trim failure.

Product Brief

RV150X00C22 Fisher V150 Vee-Ball control valve Cavitrol Hex anti-cavitation retrofit kit,used for high differential pressure oil and gas pipeline process,anti-cavitation trim spare kit.
