Fisher SR8-2SPS4 Sanitary Backpressure Regulator

Technical Specifications

Model：SR8-2SPS4 Brand：Fisher Product Type: Type SR8 direct operated sanitary backpressure regulator

Module Feature

Fisher SR8-2SPS4 is compact high capacity direct-acting sanitary backpressure regulator. Polished stainless steel body with self-draining internal structure, Tri-Clamp sanitary connection. It maintains constant upstream backpressure for liquid, gas or steam media. Supports CIP / SIP cleaning process, suitable for hygienic production environment. Widely applied in pharmaceutical, biotech, food & beverage process pipeline.

Working principle: Diaphragm senses inlet pressure and balances against spring force to modulate valve opening and stabilize upstream backpressure Onboard components: 316L stainless steel body, diaphragm assembly, valve plug & seat, pressure adjustment spring, Tri-Clamp end connections

LED indicators

Not equipped

Hardware self-diagnosis

Visual inspection, diaphragm & seat surface inspection, pressure setpoint test, tightness and shutoff leakage test

Programming software

No dedicated software required

Pneumatic & Process Parameters

Max inlet pressure:210psig (14.5bar) Spring range:2~125psig Medium:Liquid, gas, saturated steam End connection:Sanitary Tri-Clamp

Mechanical & Structure

Mounting:Pipeline installation, vertical spring case orientation recommended for self-draining Protection class:IP66

Environmental

Operating temperature:-28℃ ~ +204℃, depends on diaphragm and seat material Ambient humidity:5~95% non-condensing Certification:CE, sanitary compliance Status:Fisher SR8 series sanitary backpressure regulator

System compatibility

Installed on hygienic process pipeline, matched with sanitary filter, control valve and sanitary instrumentation.

Function

SR8-2SPS4 is sanitary backpressure regulator manufactured by Fisher. It monitors upstream pipeline pressure and automatically adjusts valve opening to keep backpressure stable. Self-draining design prevents medium residue, meets CIP/SIP cleaning requirement. Damaged diaphragm or scratched seat will cause pressure drifting and internal leakage. It is used to protect sanitary process equipment and maintain stable pipeline backpressure.

Installation

Follow lockout/tagout safety procedure before installation. Isolate pipeline and release residual medium pressure. Mount SR8-2SPS4 via Tri-Clamp sanitary fittings, follow flow direction marked on valve body. Keep spring housing upright for self-draining. Set target backpressure by adjusting top spring knob. Perform pressure holding test and leakage inspection.

Interface

Tri-Clamp sanitary clamp connection for pipeline, spring adjuster on top housing, no LED indicators on SR8-2SPS4.

Diagnostic

Backpressure unstable: Diaphragm fatigue or seat contamination. Cannot maintain set pressure: Seat surface scratch or erosion. Medium external leakage: Tri-clamp gasket damage or loose clamp.

Product Brief

SR8-2SPS4 Fisher Type SR8 stainless steel sanitary backpressure regulator,Tri-Clamp connection with CIP/SIP capability,for pharmaceutical and food hygienic pipeline backpressure control,self-draining direct-operated process regulator.
