Fives Group 502-03549-02 Serial Communication Module

Technical Specifications

Model： 502-03549-02

Brand： Fives Group

Product Type: Rack mount serial communication PCB assembly for legacy CNC system

Module Feature:

Function: Serial communication interface module for Fives Group CNC platform. Handles serial data transmission and reception for NC program upload/download, external peripheral connection and remote diagnostic data exchange for heavy horizontal boring mills and large machining centers.

Interface type: Serial asynchronous communication port Bus interface: Parallel backplane bus for bidirectional data exchange with CNC CPU

Onboard components: Serial transceiver chip, data buffer, baud rate configuration logic, surge protection circuit

LED indicators: POWER, TX, RX, FAULT diagnostic lights

Hardware self-diagnosis: Transmit / receive loopback test, signal integrity check, backplane bus verification

Programming software: Fives Group proprietary CNC software for baud rate setup, communication protocol configuration and diagnostic test

Electrical Parameters

Backplane supply: +5VDC

Power consumption: Max 6.8W

Mechanical & Structure:

Mounting: Rack slot mount with gold finger edge connector

Weight: 0.87kg

Protection class: IP20

Environmental:

Operating temperature: 0℃ ~ +55℃

Ambient humidity: 5~85% non-condensing

Certification: CE

Status: Manufacturer discontinued legacy serial communication module

System compatibility

Compatibility description: 502-03549-02 belongs to Fives Group CNC communication board family. Compatible with Fives Group CPU, memory boards and other rack modules. Widely fitted on heavy Fives Group horizontal boring mills.

Function

Function description: 502-03549-02 is serial communication board manufactured by Fives Group. It establishes serial data link between CNC controller and external peripherals such as program readers and data terminals. It supports CNC part program import and export, and uploads machine alarm and status data for remote troubleshooting. Built-in surge suppression protects communication circuit from electrical interference. It is legacy serial communication spare for heavy CNC boring mills.

Installation

Installation steps: Follow lockout/tagout safety procedure before installation. Cut off rack +5V backplane power. Insert 502-03549-02 board into rack slot and secure gold finger connector. Wire serial communication cable to the signal terminal. Configure baud rate and communication parameters via CNC software. Power on rack, verify TX and RX LED indicators, perform loopback test and test program transfer function.

Interface

Interface list: Backplane gold finger connector, serial signal screw terminal block,on-board POWER / TX / RX / FAULT LED indicators for Fives Group 502-03549-02.

Diagnostic

Troubleshooting: Cannot transfer program: Check cable wiring, baud rate mismatch or faulty transceiver chip. FAULT LED lit: Backplane communication failure or serial port short-circuit. Intermittent data loss: Electromagnetic interference, poor grounding or aging buffer chip.

Product Brief

Brief description: 502-03549-02 is Fives Group legacy serial communication interface board,for CNC part program upload and download and peripheral data connection on heavy CNC boring mills,discontinued CNC serial link PCB spare.
