Fives Group PICO-101 HMI Operator Panel

Technical Specifications

Model： PICO-101

Brand： Fives Group (Giddings & Lewis)

Product Type: Panel mount compact industrial keypad HMI for legacy PIC900 CNC / PLC system

Module Feature:

Function: PICO-101 compact operator HMI terminal for Fives Group PIC900 CNC platform. Serves as machine operator interface, supporting manual jog operation, alarm message display, CNC parameter input and simple part program viewing, widely fitted on heavy horizontal boring mills and large machining centers.

Display: Monochrome LCD graphic display Communication Interface: RS232, RS422 serial port Onboard components: Monochrome LCD module, membrane keypad array, serial communication controller, flash memory for HMI project storage, watchdog circuit

LED indicators: POWER, COM, ALARM diagnostic lights

Hardware self-diagnosis: Power-on self-test, HMI project integrity check, serial communication link detection

Programming software: Fives Group proprietary CNC software for screen project editing, download and backup

Electrical Parameters

Power supply: 24VDC

Power consumption: Max 12W

Mechanical & Structure:

Mounting: Cabinet panel cutout mounting Weight: 1.15kg

Protection class: IP65 (front panel)

Environmental:

Operating temperature: 0℃ ~ +50℃

Ambient humidity: 5~85% non-condensing

Certification: CE

Status: Manufacturer discontinued legacy PIC900 compact HMI operator panel

System compatibility

Compatibility description: PICO-101 belongs to Fives Giddings & Lewis PIC900 CNC operator interface family. Native compatible with PIC900 CNC controller. Widely installed on heavy Fives / Giddings & Lewis horizontal boring mills.

Function

Function description: PICO-101 is compact monochrome keypad HMI manufactured by Fives Group (Giddings & Lewis). It connects directly to PIC900 CNC controller via serial port. Machine operators use membrane keys to jog axes, check machine fault alarms, adjust CNC parameters and view running status. Front panel IP65 rating provides protection against workshop dust and coolant splashing. It is legacy compact operator display spare for heavy CNC boring mills.

Installation

Installation steps: Follow lockout/tagout safety procedure before installation. Cut off 24VDC panel power. Insert PICO-101 into cabinet cutout and lock mounting clips. Wire 24VDC power cable and RS232/RS422 serial communication cable to PIC900 CNC controller. Download HMI screen project via Fives proprietary programming software. Restore power, verify POWER and COM LED indicators, test LCD display and keypad operation.

Interface

Interface list: RS232 port, RS422 port, 24VDC power terminal,on-board POWER / COM / ALARM LED indicators for Fives Group PICO-101.

Diagnostic

Troubleshooting: Blank LCD screen: Check 24VDC incoming supply or backlight failure. COM / ALARM alarm: Serial cable wiring error, wrong communication protocol or baud rate mismatch. Keypad no response: Membrane keypad aging or HMI project corruption.

Product Brief

Brief description: PICO-101 is Fives Group discontinued PIC900 compact keypad HMI panel,used as native operator interface for Fives Giddings & Lewis PIC900 CNC heavy boring mills,legacy CNC operator terminal spare.
