Foxboro 130FB‑N4 Pneumatic Controller Power Module

Technical Specifications

Model:130FB‑N4

Brand:Foxboro

Application:Power supply unit for 130 series pneumatic indicating controller

Supply pressure:20psi instrument air

Signal range:3‑15psi pneumatic input / output

Air consumption:0.5m³/h under automatic mode;1.0m³/h under manual mode

Zero‑shift:max 0.35% span per 1psi supply pressure variation

Mechanical structure:force‑balance bellows mechanism

Mounting:panel mounting for control room cabinet

Protection class:IP20

Horizontal operating temperature:‑20℃ ~ +60℃

Storage temperature:‑40℃ ~ +85℃

Built‑in function

130FB‑N4 pneumatic power module provides stable instrument air source for Foxboro 130 series pneumatic PID controllers. Force‑balance bellows mechanical design ensures long‑term stable performance for loop control in chemical and petro‑chemical process sites.

Product Brief

130FB‑N4 belongs to Foxboro 130 series pneumatic control family,obsolete legacy spare part. Matching 130‑series controller main body and air pipe fittings need to be ordered separately. Widely used for original Foxboro automation equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation
