Foxboro AD198GV I/A Series Digital Input FBM Module

Technical Specifications

Model:AD198GV

Brand:Foxboro

System compatibility:I/A Series DCS control system

Function:Field discrete dry‑contact signal acquisition,transmit field equipment status to DCS controller

Installation:Standard rack‑mount slot,direct baseplate backplane fieldbus connection

Feature:Support hot‑swap replacement without rack power‑off

Input type:Field dry‑contact / potential‑free discrete contact input

Channel protection:On‑board surge suppression and transient over‑voltage protection for each channel

Diagnostic:Multi‑color LED indicators for module power,fieldbus communication and per‑channel on‑off status

Communication:Interact with I/A Series controller via I/A fieldbus backplane

Environmental standard:Compliant with ISA‑S71.04 Class G3 industrial atmospheric condition

Housing:Aluminum alloy ribbed metal housing,anti‑vibration mechanical reinforcement

Protection class:IP20

Horizontal operating temperature:0℃ ~ +60℃

Vertical operating temperature:‑20℃ ~ +55℃

Storage temperature:‑40℃ ~ +85℃

Relative humidity:5%‑95% non‑condensing

Weight:0.47kg

Dimensions:36mm × 128mm × 144mm

Certification:CE,UL

MTBF:>90000 hours

Built‑in function

AD198GV digital input FBM module collects potential‑free contact status signals from field switches,relays and interlock devices,then transmits discrete status data to I/A Series controller through rack backplane fieldbus. Independent surge‑suppression circuit restrains field‑side transient interference to avoid channel damage. Per‑channel LED visual diagnosis helps field technicians rapidly identify channel on‑off state and fault conditions. Hot‑swap function enables online module replacement and reduces plant shutdown risk,widely applied for interlock‑signal collection of petrochemical,power‑plant and chemical process systems.

Product Brief

AD198GV belongs to Foxboro I/A Series legacy DCS spare‑part family,obsolete original automation component. It must be matched with corresponding I/A Series baseplate and instrument rack. Widely used for original Foxboro DCS equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation
