Foxboro C0136HZ Control Relay Replacement Assembly

Technical Specifications

Model:C0136HZ

Brand:Foxboro

System compatibility:Spec‑200 analog DCS system

Function:Electromechanical relay switching assembly,realize discrete logic contact output for interlock,alarm and auxiliary control signals

Installation:Standard Spec‑200 rack‑slot installation,direct backplane bus connection

Contact type:SPDT electromechanical relay contact

Contact rating:24‑250VAC / 24‑125VDC, max 5A resistive load

Internal circuit:Built‑in RC surge‑suppression circuit for relay coil

Diagnostic:On‑board LED indicator for relay actuation status

Mechanical life:>10⁷ operations mechanical lifespan

Electrical life:>10⁵ operations under rated resistive load

Environmental standard:Compliant with ISA‑S71.04 Class G3 industrial atmospheric condition

Housing:Metal shielded plug‑in housing,anti‑vibration mechanical reinforcement

Protection class:IP20

Horizontal operating temperature:0℃ ~ +60℃

Vertical operating temperature:‑20℃ ~ +55℃

Storage temperature:‑40℃ ~ +85℃

Relative humidity:5%‑95% non‑condensing

Weight:0.50kg

Dimensions:34mm × 126mm × 142mm

Certification:CE,UL

MTBF:>86000 hours

Built‑in function

C0136HZ control relay replacement assembly receives logic drive signal from Spec‑200 rack backplane bus and drives built‑in electromechanical relay to complete dry‑contact switching. It outputs interlock,alarm and auxiliary control signals for field‑side devices. Internal RC surge‑suppression circuit absorbs coil reverse electromotive force and protects internal rack circuit. Front‑panel LED visually reflects relay actuation state for quick on‑site troubleshooting,widely applied for safety interlock and alarm‑logic loops in petrochemical,chemical and power‑plant Spec‑200 DCS cabinets.

Product Brief

C0136HZ belongs to Foxboro Spec‑200 legacy DCS logic‑output spare‑part family,obsolete original plug‑in automation component. Must be fitted in matching Spec‑200 instrument rack with correct field contact‑loop wiring. Widely used for original Foxboro DCS equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation
