Foxboro E20S‑V2FB6 Fieldbus Expansion Module

Technical Specifications

Model:E20S‑V2FB6

Brand:Foxboro

System compatibility:I/A Series DCS system,fieldbus capacity‑expansion unit

Function:Fieldbus expansion module,extends fieldbus communication link and expands I/O station access quantity for I/A‑Series subsystem

Installation:Baseplate‑mount installation,mated with corresponding FBM baseplate assembly

Feature:Support hot‑swap online replacement without subsystem power‑off

Diagnostic:Front‑panel multi‑color LED for module power and fieldbus communication status

Power supply:Powered via FBM baseplate backplane

Protection:Transient surge protection for fieldbus signal lines

Environmental standard:Compliant with ISA‑S71.04 Class G3 industrial atmospheric condition

Housing:Aluminum alloy metal housing,slot‑in mechanical locking structure

Protection class:IP20

Horizontal operating temperature:0℃ ~ +60℃

Vertical operating temperature:‑20℃ ~ +55℃

Storage temperature:‑40℃ ~ +85℃

Relative humidity:5%‑95% non‑condensing

Weight:1.01kg

Dimensions:37mm ×129mm ×145mm

Certification:CE,UL

MTBF:>81000 hours

Built‑in function

:E20S‑V2FB6 fieldbus expansion module expands fieldbus communication capacity for legacy Foxboro I/A‑Series DCS system. It realizes extension of fieldbus trunk to access more remote FBM I/O stations. Hot‑swap function supports online module replacement and reduces plant downtime risk. Status LED facilitates on‑site communication fault diagnosis,widely applied for subsystem capacity‑expansion and communication‑link maintenance in petrochemical,chemical and power‑plant facilities.

Product Brief

E20S‑V2FB6 belongs to Foxboro I/A Series legacy DCS fieldbus‑expansion spare‑part family,obsolete original baseplate‑mount expansion module component. Must match with corresponding FBM baseplate assembly. Widely used for original Foxboro DCS equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation.
