Foxboro FBM220 Fieldbus Communication Interface Module

Technical Specifications

Model:FBM220(P0917HA)

Brand:Foxboro

System compatibility:I/A Series DCS Standard‑200‑series fieldbus I/O subsystem,works with FCP/FCM controller,matched with Standard‑200‑series baseplate and corresponding termination assembly

Function:Standard‑200‑series communication interface fieldbus module,acts as protocol gateway between I/A‑Series DCS and external Modbus RTU field devices,supports Modbus RTU/ASCII master‑slave communication,realizes data read‑write between DCS database and third‑party instruments,converters and drives,configurable baud rate,parity,station address parameters,supports point mapping configuration

Installation:Standard‑200‑series baseplate‑mount installation,mated with dedicated Standard‑200‑series baseplate and matched termination assembly

Communication port:RS‑485 electrical interface,Modbus RTU / ASCII protocol,baud rate range 1200‑115200bps,half‑duplex transmission

Circuit feature:Opto‑coupler isolation for communication port,communication error detection and frame check,message timeout diagnosis

Feature:Support hot‑swap online replacement without subsystem power‑off,redundant 2Mbps fieldbus communication with FCP/FCM controller,standard‑200‑series mechanical structure,not compatible with Compact‑200‑series baseplate

Diagnostic:Front‑panel multi‑color LED indicators for power,fieldbus communication and external port running status,communication fault and abnormal station status passed to DCS system

Power supply:24VDC via Standard‑200‑series baseplate backplane,typical power consumption ≤3W

Protection:Transient surge absorption for communication terminals

Environmental standard:Compliant with ISA‑S71.04 Class G3 industrial atmospheric condition

Housing:Aluminum alloy metal housing,slot‑in mechanical locking structure

Protection class:IP20

Horizontal operating temperature:‑20℃ ~ +70℃

Storage temperature:‑40℃ ~ +85℃

Relative humidity:5%‑95% non‑condensing

Weight:0.45kg

Dimensions:36mm ×128mm ×144mm

Certification:CE,UL

Built‑in function

FBM220 communication interface module serves as Modbus gateway for Foxboro I/A‑Series DCS system. It completes protocol conversion between DCS fieldbus and Modbus RTU bus,realizes data interaction with third‑party Modbus instruments,transmitters and frequency converters. Built‑in communication fault diagnosis helps locate bus wiring and slave‑station exceptions. Hot‑swap supports online module replacement without system shutdown,widely applied for accessing multi‑vendor field devices in petrochemical,chemical and power‑plant facilities.

Product Brief

FBM220(P0917HA) belongs to Foxboro I/A Series legacy DCS standard‑200‑series‑communication‑interface spare‑part family,obsolete original Modbus RTU gateway module component. Must match with Standard‑200‑series dedicated baseplate and termination assembly. Not interchangeable with Compact‑200‑series hardware. Widely used for original Foxboro DCS equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation.
