GE DS200DTBDG1A Discrete I/O Terminal Board

Feature & Principle

It receives field digital status signals and transmits them to Mark V main controller via backplane bus. Meanwhile, it receives control commands from CPU and drives internal SPDT relays to switch external loads. Input filter suppresses field interference signals, jumper settings support sink/source input mode selection, to realize interlock, alarm and auxiliary equipment on-off control.

Specifications

Model: DS200DTBDG1A Brand: GE Series: Speedtronic Mark V Digital input: 8CH, 24VDC Relay output: 8CH, Form C SPDT Relay rated capacity: 2A Input filter time: 1ms Installation: Rack plug-in Application: Steam / gas turbine control system Certification: CE

Components & Diagnostics

Signal sampling circuit, relay group, backplane connector, status LED indicator, configuration jumper. Common faults: relay contact burnout, input channel no response, bus communication failure, signal interference, board power abnormality.

Product Brief

DS200DTBDG1A I/O terminal board, GE turbine control spare widely used for power plant Mark V steam turbine and gas turbine control cabinet maintenance and replacement.
