GE IS200TRLYH1BGF TRLY Triplicated Relay Output Terminal Board

Technical Specifications

Model: IS200TRLYH1BGF

Part Number: IS200TRLYH1BGF

Brand: GE（GE Vernova）

Product Type: TRLY triple‑modular relay output termination board

Matching System: GE Speedtronic Mark VI turbine control system

Relay Channels:12‑channel plug‑in magnetic Form‑C SPDT relay outputs

Contact Rating:5A@250VAC / 30VDC resistive load

Signal Diagnosis:Built‑in relay coil current sensing, relay fault detection

Redundancy Mode:Support simplex and TMR triple‑modular redundant 2‑out‑of‑3 hardware voting

Field Voltage:Support 24VDC,125VDC,115/230VAC field loop power supply

Isolation:1500Vrms coil‑to‑contact galvanic isolation

Indicator:Per‑channel LED status indicator

Connector:Barrier‑type field terminal blocks, multi‑pin backplane connectors

Coating:BGF grade conformal coating for corrosive industrial environment

Installation:Mark VI VME rack plug‑in installation

Operating Temperature:‑40℃ ~ +70℃, non‑condensing

Protection Class:IP20

Weight:0.75kg

Dimension:330mm ×178mm ×32mm

Compatible System:Gas‑steam turbine, generator unit safety shutdown control cabinet

Core Function: TRLY safety‑class relay output terminal board for Mark VI turbine control system. It receives control commands from main processing boards, converts logic signals into physical Form‑C relay contact outputs to drive field solenoid valves, trip relays and emergency shutdown loops. Built‑in coil‑sensing diagnostic function monitors relay working status in real‑time. Supports TMR triple‑modular redundant hardware voting, meets SIL3 safety requirement, realizes turbine emergency trip, safety interlock and protection output function.

Product Details

The IS200TRLYH1BGF is TRLY series triplicated relay output terminal board for GE Speedtronic Mark VI turbine control system.

This VME rack‑mounted board adopts plug‑gable magnetic relay design, 12 independent Form‑C SPDT relay channels are available for safety‑critical loop control. It supports jumper configuration for multiple field working voltages, adapts to various turbine trip circuit requirements. The unique coil‑sensing circuit can detect relay coil excitation abnormity, upload fault diagnosis information to controller. Each channel is equipped with LED indicator for convenient on‑site inspection and fault troubleshooting. BGF conformal coating enhances moisture‑proof, dust‑proof and anti‑corrosion performance, effectively resists voltage surge and electromagnetic interference from field cables.

It supports simplex and TMR triple‑modular redundant system configuration, widely applied for emergency shutdown protection of gas‑steam turbo‑generator units.

It belongs to safety‑critical spare‑part for Mark VI turbine control system, widely used in overhaul and renovation projects of power generation units.

It is important spare hardware for turbine safety trip loop debugging and defective IS200TRLYH1BGF board replacement.
