GE IS220PPDAH1B Power Distribution Feedback I/O Pack, 336A5026ADP14

Technical Specifications

Model: IS220PPDAH1B, 336A5026ADP14

Brand: GE（GE Vernova）

Product Type: PPDA power distribution feedback I/O pack

Matching System: GE Speedtronic Mark VIe turbine control system

Nominal Input: 24‑28VDC

Power Consumption: 8W

Communication: Dual redundant IONet Ethernet RJ45 ports

Mounting: Plug‑in daughter module for JPDM / JPDC / JPDS power distribution board

Diagnostic Function: Multi‑channel power bus real‑time monitoring, fuse status detection, ground fault detection

Feature: Electronic ID identification, hot‑swap plug‑and‑play support

Indicator: Front‑panel LED for power, network link and power‑channel fault status

Operating Temperature:‑40℃ ~ +70℃, non‑condensing

Humidity:5%‑95% non‑condensing

Protection Class:IP20

Weight:0.50kg

Dimension:122mm ×84mm ×42mm

Compatible System: Gas turbine, steam turbine, generator control cabinet

Core Function

PPDA power distribution feedback I/O pack for Mark VIe turbine control system. It is installed on JPD series power distribution board, responsible for real‑time monitoring of DC power bus, fuse state and ground fault signals inside the control rack. It transmits power‑supply diagnostic data to main controller via redundant IONet bus, realizes early warning of power‑loop abnormality. It supports plug‑and‑play replacement without manual re‑configuration. It applies to simplex and TMR triple‑modular redundant turbine control configuration, improves power‑supply fault visibility for the whole control rack and enhances unit operation safety.

Product Details

The IS220PPDAH1B with part number 336A5026ADP14 belongs to PPDA series power distribution feedback I/O pack for GE Speedtronic Mark VIe turbine control system.

This compact plug‑in daughter board cooperates with JPDM, JPDC or JPDS power distribution base board to collect multi‑group power‑bus feedback signals, including fuse blow‑out detection and ground‑fault monitoring. Dual IONet redundant Ethernet uploads all power‑supply status and fault information to Mark VIe main controller, so operators can locate power‑loop risks in advance before hardware failure causes turbine trip. Built‑in electronic ID chip realizes automatic system identification, supports hot‑swap plug‑and‑play replacement, simplifies on‑site maintenance work. Front‑panel LED indicators clearly display module power, network communication and channel fault conditions for quick inspection. Conformal coated circuit board improves anti‑vibration, moisture‑proof and anti‑electromagnetic‑interference performance, adapts to harsh working conditions of power‑plant turbine cabinet. Widely deployed in simplex and TMR triple‑modular redundant gas‑steam turbine control cabinets.

It belongs to critical power‑supply monitoring spare‑part for Mark VIe turbine control system, widely used in overhaul and renovation projects of power generation units.

It is important spare hardware for power‑distribution loop debugging and defective IS220PPDAH1B module replacement.
