GG16E1HEE7X2XRX207E Turbine Control Circuit Board

Feature & Principle

It is a dedicated signal processing board for heavy-duty gas turbine control system. It collects rotating speed, vibration, exhaust temperature and analog protection signals, carries out filtering, isolation and conversion, and transmits valid data to the main governor controller for closed-loop regulation and protection judgment. It has multiple analog and digital channels, and adopts anti-interference design to adapt to the harsh electromagnetic environment of power plant. This model is discontinued and only used for unit maintenance and replacement.

Specifications

Model: GG16E1HEE7X2XRX207E Brand: Gas turbine original accessory Power supply: 24VDC Signal type: Analog input, digital input/output Mounting: Rack slot installation Application: Heavy-duty gas turbine, power plant turbine control cabinet Certification: CE

Components & Diagnostics

Signal isolation circuit, filter circuit, AD conversion chip, backplane connector, status LED. Common faults: signal drift, channel damage, poor backplane contact, component aging, communication interruption.

Product Brief

GG16E1HEE7X2XRX207E turbine signal processing board, gas turbine control spare widely used for power plant gas turbine cabinet overhaul and replacement.
