Giddings & Lewis 028-25574-03 Analog Input Output Module

Technical SpecificationsModel：028-25574-03 Brand：Giddings & Lewis Product Type: Single-slot plug-in analog I/O module for PiC900 CNC rack backplane

Module Feature:Function: Analog input and output module for PiC900 CNC system, collects analog field signals and outputs analog control signals for spindle, hydraulic and coolant monitoring. Signal type: ±10V analog input / ±10V analog output Channel: Multi-channel analog input and analog output Resolution: 12-bit analog to digital and digital to analog conversion Signal isolation: Galvanic isolation between field side and CNC backplane LED indicators: OK, ACT, FAULT diagnostic lights Hardware self-diagnosis: Overrange detection, channel status monitoring, backplane bus communication check Programming software: PiCPro configuration software

Electrical ParametersBackplane supply:+5V and +3.3V from PiC900 rack Field signal: ±10V analog signal Power consumption:Max 3.2W No external field power required

Mechanical & Structure:Mounting:Plug into PiC900 rack single slot Weight:0.20kg Protection class:IP20

Environmental:Operating temperature:0℃ ~ +60℃ Ambient humidity:5~85% non-condensing Certification:CE Status:Manufacturer discontinued legacy CNC control module

System compatibility028-25574-03 belongs to Giddings & Lewis PiC900 control family. Compatible with PiC900 backplane,CPU processor board and other I/O modules. Widely applied on G&L horizontal boring mills and CNC machining centers for pressure, temperature and speed analog signal processing.

Function028-25574-03 is PiC900 analog I/O board manufactured by Giddings & Lewis. It converts field analog sensor signals into digital data for CNC system, and converts CNC digital commands to analog output to control spindle speed or proportional hydraulic valves. Galvanic isolation protects CNC rack from field noise interference. It is commonly used for hydraulic pressure, lubrication and spindle speed monitoring on heavy machine tools.

InstallationFollow lockout/tagout safety procedure before installation. Cut off rack backplane power. Insert 028-25574-03 module into PiC900 backplane slot and lock retainer. Connect shielded analog sensor and actuator cables. Configure channel scaling and signal range in PiCPro software. Power on and verify analog signal reading and output.

InterfacePiC900 backplane gold-edge connector,terminal block for analog field wiring,on-board OK / ACT / FAULT LED indicators for Giddings & Lewis 028-25574-03.

DiagnosticIncorrect analog reading:Check cable shielding, signal wiring or channel scaling parameter. FAULT LED lit:Backplane communication error or channel overrange alarm. No analog output:Channel configuration disabled or field device wiring fault.

Product Brief028-25574-03 is Giddings & Lewis legacy PiC900 analog I/O module,for analog signal collection and control output on heavy CNC boring mills and machining centers,discontinued CNC spare card.
