Giddings & Lewis M.1301.2076 Motion Control Module

Technical Specifications

Model： M.1301.2076

Brand： Giddings & Lewis

Product Type: Rack mount real-time motion control PCB assembly for PiC900 CNC system

Module Feature:

Function: Real-time motion control board for G&L PiC900 CNC platform. It receives trajectory commands from main CPU, performs closed-loop position and velocity servo calculation, exchanges servo data with servo drives for heavy horizontal boring mills and large machining centers.

Signal interface: Backplane parallel bus, auxiliary serial diagnostic port

Onboard components: Industrial motion processor, RAM for axis parameters, programmable logic chips

LED indicators: OK, RUN, AXIS FAULT, FAULT diagnostic lights

Hardware self-diagnosis: Backplane communication test, watchdog timeout detection, axis parameter integrity check

Programming software: PiCPro for axis configuration, servo parameter setup and module fault diagnosis

Electrical Parameters

Supply: +5VDC backplane power

Power consumption: Max 12W

Backup memory: Lithium battery for retention of axis servo parameters

Mechanical & Structure:

Mounting: Electrical cabinet rack slot mount with gold finger connector

Weight: 1.1kg

Protection class: IP20

Environmental:

Operating temperature: 0℃ ~ +55℃

Ambient humidity: 5~85% non-condensing

Certification: CE

Status: Manufacturer discontinued legacy PiC900 motion control board

System compatibility

Compatibility description: M.1301.2076 belongs to Giddings & Lewis PiC900 motion control family. Compatible with PiC900 CPU, SERCOS or analog servo interface modules and G&L series servo motors. Widely fitted on heavy G&L horizontal boring mills.

Function

Function description: M.1301.2076 is motion control board manufactured by Giddings & Lewis. It handles real-time trajectory interpolation and closed-loop servo control for machine axes. It communicates with PiC900 main processor over backplane bus, exchanges motion commands and feedback signals with servo drives. The onboard backup battery keeps axis tuning parameters saved during power interruption. It is legacy motion spare for heavy G&L CNC boring mills.

Installation

Installation steps: Follow lockout/tagout safety procedure before installation. Cut off rack backplane power. Insert M.1301.2076 into rack slot and secure gold finger connector. Install backup battery before power-up. Connect serial diagnostic cable. Configure axis parameters and servo gains via PiCPro. Run self-test and verify axis jog, homing and machining motion performance.

Interface

Interface list: Backplane gold finger connector, serial diagnostic port,on-board OK / RUN / AXIS FAULT / FAULT LED indicators for Giddings & Lewis M.1301.2076.

Diagnostic

Troubleshooting: AXIS FAULT: Servo gain mismatch, mechanical overload or encoder signal loss. FAULT LED lit: Backplane communication failure or onboard memory fault. Parameter loss: Depleted backup battery or poor battery contact.

Product Brief

Brief description: M.1301.2076 is Giddings & Lewis legacy PiC900 motion control board,for real-time axis trajectory and closed-loop servo control on heavy CNC boring mills,discontinued CNC motion spare PCB.
