HIMA ELOPII Engineering Software

Technical Specifications

Model:ELOPII

Brand:HIMA

Product Type:Safety engineering configuration & programming software

Certification:SIL3,IEC61508,TÜV certified

Supported hardware:H41q,H51q HIQuad, HIMatrix safety controllers

Programming standard:IEC 61131-3

Main functions:Logic editing,offline simulation,hardware configuration,program download,online monitoring,fault diagnosis,SOE event recording

License:USB hardware dongle or software license file

Compatible OS:Windows XP / Windows 7

Operating temperature:PC operating ambient -20~+60℃

Relative humidity:5~95% non-condensing

System compatibility:Designed for HIMA HIQuad H41q/H51q and HIMatrix safety control systems,widely used in petrochemical,chemical plant ESD emergency shutdown and F&G fire gas protection system.

Function:Certified safety engineering platform.Used to build safety logic,configure hardware I/O structure,run offline simulation test,download compiled program to safety controller,real-time online monitoring and fault diagnosis,record sequence of events.

Installation:Install on engineering PC,activate via license dongle,connect to HIMA safety rack with dedicated communication cables for program upload/download.

Interface:

‑Graphical engineering user interface

‑Serial/RS485/Fiber communication interface to safety rack

‑Offline simulation interface for logic verification

Feature:TÜV certified safety software,strict functional safety verification,redundant system synchronization management,comprehensive diagnostic information reading. Common issues:license dongle failure,version mismatch with controller firmware,communication connection failure.Confirm controller firmware version before use.

Diagnostic:Software can read all system alarms,channel faults,bus communication status and SOE event logs of HIMA safety controlle

Built‑in function

ELOPII covers full life cycle of SIS safety project from design,simulation,commissioning to maintenance,widely used for chemical and power plant safety system engineering work.

Product Brief

ELOPII is HIMA professional SIL3 certified safety engineering software for H41q,H51q and HIMatrix safety instrumented system. Match software version with controller firmware before deployment. Test program download and online communication during commissioning. ESD anti‑static protection shall be followed for connected hardware.
