HIMatrix B4235 H41q-MS Assembly Kit

Technical Specifications

Model:B4235

Brand:HIMA(HIMatrix)

Safety certification:SIL3,IEC61508,TÜV certified

Rack specification:19 inch,5U height

Slot quantity:13 slots for I/O and plug-in modules

Included accessories:Backplane K1409,4pcs fan modules,cable tray,label holder

Power bus:24V DC input,5V internal backplane power

Mounting:19 inch cabinet installation

Protection class:IP20

Operating temperature:-20~+60℃

Relative humidity:5~95% non-condensing

Weight:12.5kg

Certification:CE,ATEX compliant

System compatibility:Matches HIMA H41q-MS safety control system,supports F8652 CPU,power supply and I/O modules,for petrochemical,chemical plant ESD emergency shutdown and F&G fire gas protection system.

Function:Complete pre-assembled safety rack kit for H41q-MS system.Provides backplane bus,module slots and forced air cooling,serves as hardware carrier for safety CPU,power and I/O modules.

Installation:Install 5U rack into 19-inch control cabinet,fix mounting bolts,install CPU,PS and I/O modules into slots,wire power and field signals.

Interface:

‑Backplane internal system bus

‑AC/DC power terminal block

‑Fan fault signal terminals

‑Module front slot openings

Circuit feature:Stable backplane bus design,built-in fan diagnostic,anti-electromagnetic interference,meets SIL3 functional safety requirements for hazardous industrial environment.

Feature:HIMatrix H41q-MS complete rack assembly kit B4235,contains rack,backplane and cooling fans. Common faults:backplane circuit damage,fan failure,terminal corrosion.Confirm H41q-MS system version before replacement.

Diagnostic:Rack backplane fault causes all modules communication failure;fan fault triggers rack overheat alarm.

Built‑in function

B4235 provides rack hardware platform for H41q-MS safety interlock and emergency shutdown system,widely used for chemical and power plant SIS spare replacement.

Product Brief

B4235 belongs to HIMA H41q-MS rack assembly family,5U 19-inch SIL3 safety subrack kit with 13 I/O slots. Verify system version and module compatibility before ordering. Check backplane bus communication and fan function during commissioning. ESD anti‑static protection shall be followed during installation.
