HIMatrix B5231 H51q-MS Rack Assembly Kit

Technical Specifications

Model:B5231

Brand:HIMA(HIMatrix)

Safety certification:SIL3,IEC61508,TÜV certified

Rack specification:19 inch,5U height

System: H51q-MS

Slot quantity:13 slots for I/O and plug-in modules

Included accessories:Backplane,4pcs fan modules,cable tray,ground bar

Power bus:24V DC input,5V internal backplane power

Mounting:19 inch cabinet installation

Protection class:IP20

Operating temperature:-20~+60℃

Relative humidity:5~95% non-condensing

Weight:12.6kg

Certification:CE,ATEX compliant

System compatibility:Matches HIMA H51q-MS safety rack system,supports H51q series CPU,power supply and I/O modules,for petrochemical,chemical plant ESD emergency shutdown and F&G fire gas protection system.

Function:Pre-assembled safety rack kit for H51q-MS system.Provides backplane bus,module slots and forced air cooling,serves as hardware carrier for safety CPU,power and I/O modules.

Installation:Install 5U rack into 19-inch control cabinet,fix mounting bolts,install CPU,PS and I/O modules into slots,wire power and field signals.

Interface:

‑Backplane system bus connector

‑24V DC power terminal block

‑Fan fault signal terminals

‑Module front slot openings

Circuit feature:Stable backplane bus design,built-in fan diagnostic,anti-electromagnetic interference,meets SIL3 functional safety requirements for hazardous industrial environment.

Feature:HIMatrix H51q-MS complete rack assembly kit B5231. Common faults:backplane circuit damage,fan failure,terminal corrosion.Confirm H51q-MS system version before replacement.

Diagnostic:Rack backplane fault causes all modules communication failure;fan fault triggers rack overheat alarm.

Built‑in function

B5231 provides rack hardware platform for H51q-MS safety interlock and emergency shutdown protection,widely used for chemical and power plant SIS spare replacement.

Product Brief

B5231 belongs to HIMA H51q-MS rack assembly family,5U 19-inch SIL3 safety subrack kit with 13 I/O slots. Verify system version and module compatibility before ordering. Check backplane bus communication and fan function during commissioning. ESD anti‑static protection shall be followed during installation.
