HIMatrix BV7043 Data Connecting Cable

Technical Specifications

Model:BV7043

Brand:HIMA(HIMatrix)

Cable type:Shielded LiYCY 4×0.25mm²

Connector:9-pin MIN-D socket

Available length:5m,15m

Power:No external power required

Application:PC direct connection to H41q / H51q system interface

Protection:Shielded,anti-interference

Operating temperature:-20~+60℃

Relative humidity:5~95% non-condensing

Weight:0.3kg

Certification:CE

System compatibility:Used for HIMA H41q and H51q HIQuad safety systems,connects laptop/PC to safety rack for programming,parameter download,online diagnosis and HIKA communication analyzer testing.

Function:Dedicated shielded communication cable,realizes direct serial connection between PC and H41q/H51q safety controller.Used to upload/download safety program,view diagnostic alarms and complete system commissioning via SILworX.

Installation:Connect one end to H41q/H51q dedicated interface port,the other end to PC serial port or adapter.

Interface:

‑9 pin MIN-D connector for rack side

‑9 pin terminal for PC side

Circuit feature:Shielded twisted pair cable,good noise suppression,stable communication,designed for industrial harsh environment.

Feature:HIQuad system dedicated programming and diagnostic cable BV7043. Common faults:cable core break,connector pin damage,shielding layer failure.Confirm system series before replacement.

Diagnostic:Cable damage will cause communication failure between PC and safety controller,unable to read system status or download program.

Built‑in function

BV7043 provides communication link between PC and H41q/H51q SIS safety rack for commissioning and maintenance,widely used for chemical and power plant safety spare replacement.

Product Brief

BV7043 belongs to HIMA HIQuad system communication cable family,shielded 9-pin MIN-D data cable for H41q/H51q commissioning and diagnostic. Verify system model before ordering. Check communication connection during commissioning. ESD anti‑static protection shall be followed during installation.
