HIMatrix BV7052 Data Connecting Cable

Technical Specifications

Model:BV7052

Brand:HIMA(HIMatrix)

Cable type:Shielded LifYCY 3×2×0.08mm² twisted pair

Connector:9-pin MIN-D plug at both ends

Standard length:2m,4m,custom length available

Signal interface:Serial signal for single-channel PES system

Power supply:No external power required

Built-in:Matched termination resistors

Protection:Overall shielded,anti-interference

Operating temperature:-20~+60℃

Relative humidity:5~95% non-condensing

Weight:0.26kg

Certification:CE

System compatibility:Matches HIMA H7505 interface converter and single-channel H41q/H51q HIQuad safety system,for petrochemical,chemical plant ESD emergency shutdown and F&G fire gas protection system.

Function:Dedicated shielded data cable for single channel HIQuad system.Realizes serial data transmission between H7505 interface module and single-channel safety rack.Used for safety program upload/download,online fault diagnosis and system commissioning via SILworX software.

Installation:One end connects to H7505 module 9-pin port;the other end plugs into single-channel H41q/H51q rack interface.

Interface:

‑9 pin MIN-D plug (H7505 side)

‑9 pin MIN-D plug (safety rack side)

Circuit feature:Shielded twisted pair layout,built-in matched resistors,strong noise suppression,stable serial communication,meets SIL3 functional safety requirements for hazardous industrial environment.

Feature:HIQuad single channel system dedicated communication cable BV7052. Common faults:cable core break,connector pin deformation,shielding layer damage.Confirm H7505 and single-channel rack version before replacement.

Diagnostic:Cable failure causes communication interruption between H7505 and safety rack;cannot read system alarms or download safety program.

Built‑in function

BV7052 provides serial communication link between H7505 and single-channel H41q/H51q SIS safety rack for maintenance and commissioning,widely used for chemical and power plant safety spare replacement.

Product Brief

BV7052 belongs to HIMA HIQuad communication cable family,9-pin MIN-D shielded data cable for H7505 and single-channel H41q/H51q safety subrack. Verify system version before ordering. Test serial communication during commissioning. ESD anti‑static protection shall be followed during installation.
