ICS TRIPLEX T9882 Analog Output Field Termination Assembly

Technical Specifications

Model:T9882

Brand:ICS TRIPLEX

Product type:AADvance 8-channel dual isolated analog output FTA

System series:AADvance SIS

Matching module:T9482 analog output module

Mounting:DIN rail mounting

Output channels:8 analog output channels,dual isolated group architecture

Signal:4~20mA current output

Max load impedance:750Ω

Protection:50mA field replaceable fuses per channel

Wire gauge:Max 16AWG (1.31mm²)

Galvanic isolation:2500VAC channel group isolation

Operating temperature:-20~+70℃

Relative humidity:5~95% non-condensing

Weight:0.46kg

Certification:CE,TÜV,SIL3

System compatibility

T9882 belongs to ICS TRIPLEX AADvance safety instrumented system,DIN rail mounted outside main rack. It serves as field termination and signal conditioning unit for T9482 AO module,transmitting 4-20mA analog control signals to valve positioners and field actuators. Widely deployed in oil & gas,petrochemical and power plants for ESD and fire & gas safety applications.

Function

T9882 serves as high integrity dual-isolated analog output termination unit of AADvance SIS. It provides screw terminal connection,per-channel fuse protection and surge suppression for 8-channel analog output signals. Dual isolation design reduces cross-channel interference and supports simplex,dual and TMR redundant configurations.

Installation

Mount T9882 on standard DIN rail inside control cabinet. Wire field valve positioners to T9882 terminal blocks,connect signal cable from FTA to T9482 analog output module. Verify output signal quality and load diagnostics via AADvance Workbench engineering software.

Interface

‑Field screw terminal blocks for 8-channel 4-20mA analog output wiring

‑Replaceable 50mA fuses for each channel

‑Signal output terminals to T9482 AO module

‑Onboard surge suppression circuit

‑Screw type terminals for secure field wiring

Circuit feature

Rugged compact PCB design,built-in surge and overvoltage protection circuit. Dual group isolated architecture,fully compliant with SIL3 functional safety hardware specifications.

Feature

T9882 is spare dual isolated analog output FTA for ICS TRIPLEX AADvance SIS. Common faults include blown fuses,terminal loosening and load wiring open/short circuit. Confirm AO module model before replacement.

Diagnostic

When wiring fault,load abnormality or onboard hardware failure is detected,the module triggers fault alarm and uploads diagnostic messages to safety workstation.

Built‑in function

Field 4-20mA dual isolated analog signal termination,per-channel fuse overcurrent protection,surge suppression and conditioned signal transmission for T9482 analog output module,used as SIS dual isolated AO FTA spare replacement.

Product Brief

T9310-02 is ICS TRIPLEX SIL3 AADvance 8-channel dual isolated analog output FTA,DIN rail mounted,matched with T9482 analog output module for valve positioner control signal termination in dual redundant safety system. Verify system firmware compatibility before ordering. ESD anti-static protection must be followed during handling installation.
