KEBA 07F4C3D500114 KeDrive Servo Drive

Technical Specifications

Model:07F4C3D500114

Brand:KEBA

Product type:KeDrive servo drive unit

Power supply:Input 1-phase 200~240Vac,50/60Hz,8A；Output 3-phase 0~240Vac,750W,1.8kVA

Control function:Vector control,V/F control,spindle & axis motion control,built-in brake chopper,overvoltage/overcurrent/overheat/earth fault/phase loss protection,150% overload for 60s,parameter group switching,system self-diagnosis,fault alarm

Communication:RS232,CANopen,optional EtherCAT fieldbus

Mounting:Wall mounting

Operating temperature:-10~50℃（>1000m altitude derating required）

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Cooling:Natural convection

Weight:2.6kg

Dimension:210mm145mm78mm

Certification:CE

Protection class:IP20

System compatibility

07F4C3D500114 belongs to KEBA KeDrive drive system family,matched with KEBA servo motor,KePlast injection molding control system.Widely used in injection molding machinery,automated machinery control cabinets.This is a discontinued legacy servo drive for equipment maintenance spare replacement.

Function

07F4C3D500114 serves as KEBA KeDrive servo drive.It converts single-phase AC input to three-phase variable frequency PWM output,supports high-speed spindle and linear axis control.It integrates built-in brake chopper for rapid deceleration and dynamic braking.It supports vector control to maintain stable low-speed torque,multi-set parameter storage and switch.It has complete hardware fault detection and fault code display function.It is the core power drive component for KEBA plastic automation equipment.

Installation

Mount 07F4C3D500114 vertically on cabinet inner wall.Leave sufficient ventilation gap around unit.Complete power cable,motor cable and encoder wiring according to wiring drawing.Wait 5 minutes after power cut for DC bus capacitor discharge before maintenance.Check wiring insulation and cabinet ventilation before power-on.

Interface

‑AC input power terminal(L,N,PE)

‑3-phase motor output terminal(U,V,W,PE)

‑Braking resistor terminal(BR+,BR-)

‑Incremental encoder port X4

‑Operator panel interface X2

‑Option fieldbus slot X5

‑LED status and fault indicator

Circuit feature

IGBT PWM power conversion circuit,built-in EMC filter,ESD and surge suppression design.Reliable high-frequency output,strong anti-interference performance for industrial cabinet environment.

Feature

07F4C3D500114 is obsolete KEBA series spare part.Typical failures include IGBT breakdown,overheat alarm,output phase loss,communication abnormal.Check power circuit and terminal pins before replacement.This drive must match corresponding KEBA servo motor,direct substitution without inspection is not recommended.

Diagnostic

When overcurrent,overvoltage,overtemperature,phase loss or internal hardware fault occurs,the drive stops output and displays fault code on the panel.

Built‑in function:High frequency motor speed control,vector torque regulation,braking energy absorption,multi-protection monitoring,used as KEBA KeDrive series servo drive spare replacement.

Product Brief

07F4C3D500114 is KEBA old industrial series KeDrive servo drive for injection molding machine and high-speed spindle equipment.Confirm KEBA motor parameter matching before ordering.ESD protection required during handling and installation.
