KEBA CR-092 I/O Control Module

Technical Specifications

Model:CR-092

Brand:KEBA

Product type:I/O control module

Power supply:24 Vdc,max 0.8A

Control function:Field signal acquisition,digital signal output,overload and short-circuit protection,channel state monitoring,hardware self-diagnosis,fault indication

Communication:Internal backplane bus

Mounting:Plug-in rack mounting

Operating temperature:-10~55℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Weight:0.35kg

Dimension:160mm95mm30mm

Certification:CE

Protection class:IP20

System compatibility

CR-092 belongs to KEBA KePlast control system family,matched with KEBA CPU controller and I/O rack.Widely applied in injection molding machinery and automated equipment control cabinets.This is a discontinued legacy I/O control module for equipment maintenance spare replacement.

Function

CR-092 serves as KEBA I/O control module.It collects digital signals from sensors and limit switches.It receives instructions from main CPU and outputs switching signals to on-site actuators.It monitors real-time channel status and transmits fault information to the host controller via backplane bus.It acts as signal collection and transmission component for KEBA plastic machinery control system.

Installation

Insert CR-092 into the designated rack slot and lock the latch.Complete field sensor and actuator wiring according to wiring drawing.Check 24V power polarity and cabinet grounding before power-on.

Interface

‑24Vdc power terminal

‑Rack backplane connector

‑Screw terminal block for field signal

‑Channel status LED indicator

‑Module fault status lamp

Circuit feature

Isolated signal circuit,built-in ESD and surge suppression design.Stable signal transmission,strong anti-interference performance for industrial cabinet environment.

Feature

CR-092 is obsolete KEBA series spare part.Typical failures include signal channel failure,output burnout,backplane communication interruption.Check module circuit and connector pins before replacement.This module must match corresponding KEBA rack system,direct substitution without inspection is not recommended.

Diagnostic

When channel short-circuit,overload or internal hardware fault occurs,the module uploads fault information to host controller and lights up fault LED.

Built‑in function:Field digital signal acquisition and output,overload protection,channel status monitoring,self-diagnosis and fault alarm,used as KEBA KePlast series I/O control module spare replacement.

Product Brief

CR-092 is KEBA old industrial series I/O control module for injection molding machine and automated production equipment.Confirm KEBA rack and CPU model matching before ordering.ESD protection required during handling and installation.
