KEBA FB201 Digital I/O Expansion Module

Technical Specifications

Model:FB201

Brand:KEBA

Product type:Rack mount digital input output expansion module

Power supply:24 Vdc,19.2~28.8V tolerance,max 0.9A

Control function:Digital field signal collection,switch signal output,channel overcurrent and short-circuit protection,hardware self-diagnosis,fault indication

Communication:KEBA backplane bus,RS232 debug port

Mounting:Plug-in rack installation,support hot swap

Operating temperature:-10~55℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Weight:0.7kg

Dimension:260mm125mm53mm

Certification:CE

Protection class:IP20

System compatibility

FB201 belongs to KEBA ComAct control system family,matched with KEBA CPU controller and standard rack.Widely applied in injection molding,die-casting and stamping machine control cabinets.This is a discontinued legacy digital I/O expansion module for equipment maintenance spare replacement.

Function

FB201 serves as KEBA digital I/O expansion module.It collects digital signals from proximity switches,limit switches and safety gate sensors.It receives commands from main controller via backplane bus and outputs switching signals to solenoid valves,contactors and indicator lights.It adopts spring pluggable terminals for convenient wiring maintenance.It feeds back real-time channel status and fault information to host controller.It acts as field signal interface component for KEBA machinery automation system.

Installation

Insert FB201 into the designated rack slot and lock the knobs.Complete field sensor and actuator wiring according to wiring drawing.Check 24V power polarity and cabinet grounding before power-on.

Interface

‑24Vdc backplane power terminal

‑KEBA rack backplane connector

‑Spring pluggable signal terminal block

‑DB9 RS232 debug port

‑Channel status LED indicator

‑Module fault status lamp

Circuit feature

Isolated signal circuit,built-in ESD and surge suppression design.Stable digital signal transmission,strong anti-interference performance for industrial cabinet environment.

Feature

FB201 is obsolete KEBA series spare part.Typical failures include channel signal loss,output burnout,backplane communication interruption.Check module circuit and connector pins before replacement.This module must match corresponding KEBA rack system,direct substitution without inspection is not recommended.

Diagnostic

When channel short-circuit,overload or internal hardware fault occurs,the module uploads fault information to host controller and lights up fault LED.

Built‑in function:Field digital signal acquisition and switching output,overload and short-circuit protection,channel status monitoring,self-diagnosis and fault alarm,used as KEBA ComAct series digital I/O expansion module spare replacement.

Product Brief

FB201 is KEBA old industrial series rack I/O expansion module for injection molding and die-casting machine automation equipment.Confirm KEBA rack and CPU model matching before ordering.ESD protection required during handling and installation.
