Keithley 3706A System Switch Multimeter

Feature & Principle

It is a 2U rack-mounted 6-slot system switch mainframe of Keithley 3700A series. It can be equipped with various plug-in switching cards for multi-channel signal routing. The built-in optional 7.5-digit DMM realizes integrated switching and measurement. Adopting TSP test script processor, it can execute local test scripts to reduce communication delay. It supports TSP-Link expansion for multi-unit cascade and LXI Ethernet communication, widely used in electronic component automatic test and data acquisition.

Specifications

Model: 3706A Brand: Keithley (Tektronix) Slot: 6 plug-in card slots Chassis: 2U rack mount Communication: LXI Ethernet, USB, TSP-Link Processor: TSP test script processor Optional: 7.5 digit digital multimeter Max channels: Up to 576 two-wire multiplex channels Application: Semiconductor, electronic component automated test, DAQ measurement Certification: CE

Components & Diagnostics

Main control board, analog backplane, card slots, power supply module, front panel display & keypad, Ethernet/USB interface. Common faults: communication connection failure, card identification error, measurement drift, power abnormality.

Product Brief

3706A system switch multimeter, Keithley high-density automatic test measurement spare widely used for test bench overhaul and replacement.
