Kollmorgen SR6-6SMx7G Servo Cable Spare Part

Technical Specifications

Model:SR6-6SMx7G

Brand:Kollmorgen

Part No:SR6-6SMx7G

Product type:Servo motor power cable

Rated voltage:600V

Temperature range:-20℃~105℃

Shield:Full copper braid EMI shielding

Connector:6pin male power plug + 8pin feedback plug

Outer jacket:Oil resistant,wear resistant PUR material

Cable type:High-flex moving chain cable

Protection class:IP65 at connector side

Operating temperature:0~40℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE,UL

System compatibility

SR6-6SMx7G belongs to Kollmorgen SR6 servo cable family,matched with Kollmorgen 6SM series synchronous servo motors and SERVOSTAR S600 series servo drives,widely used in machine tools,handling equipment,packaging automation and linear moving axis systems.This is discontinued industrial spare part for equipment overhaul and maintenance.

Function

SR6-6SMx7G is high-flex shielded servo motor cable.It transmits three-phase power to 6SM servo motor and carries resolver/encoder feedback signals.The full shielding structure suppresses electromagnetic interference,ensuring stable signal transmission in high noise industrial environment.PUR outer sheath supports frequent reciprocating bending for drag chain installation,resists cutting,oil and chemical corrosion.

Installation

Route SR6-6SMx7G inside drag chain or cable trough.Connect motor end plug to 6SM servo motor,amplifier end plug to SERVOSTAR S600 drive.Tighten connector locking ring,separate from high-power AC cable,complete shielding grounding before power-on test.

Interface

‑6pin power connector (motor side)

‑8pin signal feedback connector

‑Copper braid shield grounding terminal

Feature

SR6-6SMx7G is obsolete Kollmorgen spare part.Typical faults:outer jacket cracking,inner wire breakage from repeated bending,shield layer damage,connector pin oxidation.Test cable continuity and insulation resistance before replacement.

Diagnostic

Cable faults will trigger motor overcurrent,feedback signal loss,random position alarm;motor jitter,intermittent operation failure,unstable speed.

Built‑in function:Transmit motor power and position feedback signals,suppress electromagnetic interference,as Kollmorgen 6SM servo motor matching high-flex cable spare replacement.

Product Brief
