Leuze CSL710-T40-610 Switching Light Curtain Transmitter Unit

Feature & Principle

This transmitter emits pulsed infrared beams to the paired receiver. It detects the presence, contour and position of objects when beams are blocked, outputs switching signals for part counting, tracking and area monitoring. It adopts through-beam optical principle and supports stable detection for high-speed automation processes.

Specifications

Model: CSL710-T40-610 Brand: Leuze Series: CSL710 Type: Transmitter Beam spacing: 40 mm Measuring field length: 610 mm Guaranteed operating range: 0.3 ~ 7 m Light source: Infrared LED, 940nm Power supply: 24VDC Connector: M12 Protection: IP67 Certification: CE

Components & Diagnostics

Infrared LED beam array, drive circuit, status indicator, M12 connector, aluminum extrusion housing. Common faults: beam misalignment, lens contamination, power supply fault, internal emitting circuit damage.

Product Brief

CSL710-T40-610 light curtain emitter, Leuze automation sensor spare widely used for material counting, object profiling and conveyor line detection.
