Motorola MVME5100 VMEbus Single Board Computer

Technical Specifications

Model:MVME5100

Brand:Motorola

Part No:MVME5100

Product type:VMEbus Single Board Computer

CPU:PowerPC 7410

Clock:450MHz

Cache:32KB I-cache,32KB D-cache,1MB L2 cache

Memory:512MB ECC SDRAM,32KB battery-backed NVRAM with RTC clock,17MB Flash memory

Bus:VMEbus A32/D32,VME64x,D64 BLT,A24/D16,A16,master/slave with DMA

Form Factor:Single-width 6U Eurocard

Power supply:+5V DC,typical 4.5A

Dimension:233mm160mm17mm

Weight:0.90kg

Interface:2×RS232 serial port,dual 10/100M Ethernet port,dual PMC expansion slots,Ultra SCSI,watchdog timer

Operating temperature:0℃ ~ +70℃ (forced air cooling)

Storage temperature:-40℃ ~ +85℃

Relative humidity:5~90% non-condensing

Certification:CE

System compatibility

MVME5100 belongs to Motorola MVME5100 VME series single board computer.It can work with standard VME backplane and matched VME I/O modules,widely used in old industrial control,test measurement and semiconductor equipment.It is spare part for legacy equipment overhaul.

Function

MVME5100 is a single-width 6U VME single board computer based on PowerPC 7410 RISC processor with AltiVec unit.It supports embedded real-time operating system such as VxWorks and RTEMS,performs control logic operation and field data acquisition.It communicates with peripheral modules via VME bus,serial ports,Ethernet and SCSI.It has onboard watchdog timer and real-time clock for reliable long-running embedded control.This variant adopts 450MHz PowerPC 7410 CPU,equipped with 512MB ECC SDRAM,dual PMC slots,Universe II VME-PCI bridge.

Installation

Insert MVME5100 into standard 6U VME chassis slot,lock the front panel.Fix the board,connect serial cable,Ethernet cable,SCSI cable and VME backplane.Take ESD protection before power-on.

Interface

‑VME backplane connector

‑Dual RS232 serial port

‑Dual 10/100M Ethernet port

‑Ultra SCSI interface

‑Dual PMC expansion slots

‑Watchdog timer

‑RTC battery backup circuit

‑+5V power terminal

Feature

MVME5100 classic industrial SBC.Typical faults:gold finger oxidation,SDRAM chip failure,serial transceiver damage,battery leakage.Clean gold finger and test memory before replacement.

Diagnostic

Fault phenomenon:no power on,boot failure,VME bus communication error,serial port no data output,Ethernet link loss,SCSI communication failure.Check VME backplane power supply,clean gold finger,test SDRAM and communication circuit.

Product Brief

MVME5100 is Motorola single-width 6U VME single board computer with PowerPC 7410 450MHz CPU,512MB ECC SDRAM,with dual serial ports,dual 10/100M Ethernet,Ultra SCSI and dual PMC shturl.c is standard temperature version,mainly used for maintenance and replacement of old VME industrial control equipment.ESD protection must be followed during handling.
