MVC77UO32A72-76 Solenoid Valve Unit

Feature & Principle

After the electromagnetic coil is energized, the pilot spool moves to change the internal pressure balance. It drives the main valve to open or close, so as to connect or cut off the fluid pipeline. It receives switch signals from PLC and relay to realize remote automatic control of gas and liquid medium.

Specifications

Model: MVC77UO32A72-76 Type: Pilot solenoid valve Controlled medium: Compressed air, water, light oil Voltage: 24VDC / 110VAC Connection: Thread connection Protection: IP65 Certification: CE

Components & Diagnostics

Electromagnetic coil, pilot spool assembly, main valve piston, valve body, sealing gasket, wiring terminal. Common faults: coil burnout, seal aging leakage, valve stuck, slow action, dirt blocking valve cavity.

Product Brief

MVC77UO32A72-76 solenoid valve, fluid control spare widely used for packaging machinery, automation production line and pneumatic system pipeline control.
