ODV10DCO Laser Displacement Sensor Unit

Feature & Principle

It adopts laser triangulation principle. The laser spot projects onto the target surface, the receiving lens captures reflected light spot, internal circuit calculates distance value and outputs standard signal for position tracking and dimension checking.

Specifications

Model: ODV10DCO Measurement type: Optical triangulation Output: Analog / digital optional Power supply: 10~30VDC Housing: Metal enclosure Protection: IP67 Certification: CE

Components & Diagnostics

Laser emitter, optical receiver, signal processing PCB, status indicator, connector. Common faults: laser contamination, signal unstable, output drift, wiring fault.

Product Brief

ODV10DCO displacement sensor, inspection spare widely used for machine tool, packaging equipment and production line online dimension monitoring.
