OXYGUARD Dissolved Oxygen Measuring Instrument Unit

Feature & Principle

It adopts galvanic cell principle. Oxygen permeates the membrane and triggers internal chemical reaction to generate electrical signal proportional to oxygen partial pressure, built-in temperature compensation. The signal is converted to standard analog or digital signal and sent to PLC or controller for oxygen monitoring and aeration interlock control.

Specifications

Brand: OXYGUARD (Denmark) Measuring principle: Galvanic cell Output: 4-20mA / Modbus optional Measuring range: 0~20mg/L, 0~200% saturation Cable: Customizable length Protection grade: IP68 submersible Certification: CE

Components & Diagnostics

Galvanic sensing cell, permeable membrane, temperature sensor, signal circuit, cable assembly. Common faults: membrane fouling, signal drift, low response, cable damage, calibration failure.

Product Brief

OXYGUARD dissolved oxygen sensor, water quality spare widely used for recirculating aquaculture, power boiler feed water and sewage treatment oxygen monitoring.
