PAC-1I Analog Input Module

Feature & Principle

It samples standard analog signals from transmitters such as pressure, flow and level sensors. After isolation and A/D conversion, the signal is transmitted to the main controller via internal bus. Isolation design suppresses ground loop interference, supports range configuration and channel fault diagnosis, ensures stable collection of field process variables.

Specifications

Model: PAC-1I Type: Single channel analog input Input signal: 4-20mA, 0-10V Isolation: Electrical isolation Power supply: 24VDC Mounting: Rack plug-in Application: Chemical, water treatment, pipeline process monitoring Certification: CE

Components & Diagnostics

Signal isolation circuit, A/D conversion chip, bus communication unit, status LED indicator, terminal block. Common faults: signal offset, no sampling value, channel burnout, bus communication interruption, wiring short circuit.

Product Brief

PAC-1I analog input module, process automation spare widely used for industrial DCS and PLC control cabinet signal acquisition replacement.
