ProSoft 5302-MBP-MCM4 Modbus Plus to Modbus Master Gateway

Technical Specifications

Model:5302-MBP-MCM4

Brand:ProSoft

Product type:Protocol Communication Gateway

Power supply:18-32VDC

Communication:Modbus Plus,4 x Modbus Master(RS232/RS485)

Weight:0.37kg

Operating temperature:-40℃ ~ +70℃

Dimension:127mm102mm35mm

Certification:CE,UL

System compatibility

5302-MBP-MCM4 belongs to ProLinx series DIN rail gateway.It connects Modbus Plus network with multiple Modbus slave devices,suitable for legacy automation system upgrade and spare replacement.

Function

It acts as Modbus Plus node and 4 independent Modbus master ports,realizes bidirectional real-time data mapping between Modbus Plus PLC and field Modbus instruments.

Installation

DIN rail mounting,connect 24VDC power,wire Modbus Plus bus and Modbus serial lines,configure data mapping via configuration software,check LED indicators.

Interface

1*DB9 Modbus Plus port,4 configurable RS232/RS485 serial terminals,power terminal,run and fault status LED indicators.

Feature

Compact DIN rail housing,four independent Modbus master channels,isolated serial ports,stable operation in industrial cabinet environment.

Diagnostic

Check power,link and fault LED;communication failure:verify bus wiring,terminal resistance,station address and baud rate;data abnormal:check register mapping and serial port configuration.

Product Brief

5302-MBP-MCM4 is ProSoft ProLinx protocol gateway,bridge Modbus Plus network and multi-drop Modbus field devices,for old industrial automation system maintenance and transformation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and renovation.
