ProSoft AN-X-AMX4 EtherNet/IP to Reliance AutoMax Gateway

Technical Specifications

Model:AN-X-AMX4

Brand:ProSoft

Product type:Protocol Communication Gateway

Power supply:18-32VDC

Communication:EtherNet/IP, Reliance AutoMax DCSNet, AutoMax Remote I/O

Weight:0.35kg

Operating temperature:-40℃ ~ +70℃

Dimension:127mm102mm35mm

Certification:CE,UL

System compatibility

AN-X-AMX4 belongs to ProSoft AN-X series DIN rail gateway.It connects modern EtherNet/IP control network with old Reliance AutoMax DCSNet and Remote I/O devices,suitable for obsolete automation system upgrade and spare replacement.

Function

It acts as EtherNet/IP adapter,realizes bidirectional real-time I/O data mapping between EtherNet/IP controller and legacy Reliance AutoMax DCSNet or Remote I/O racks,also supports network data capture function.

Installation

DIN rail mounting,connect 24VDC power,wire Ethernet and AutoMax bus,configure station address and data mapping via web configuration page,check LED indicators.

Interface

1*10/100Mbps Ethernet RJ45 port,AutoMax bus terminal,power terminal,run and fault status LED indicators.

Feature

Compact DIN rail housing,supports multiple working modes including DCSNet bridge,AMXRIO bridge and data logging,firmware upgradable over Ethernet,stable operation in industrial cabinet environment.

Diagnostic

Check power,link and fault LED;communication failure:verify network cable,bus wiring,drop address and baud rate;data abnormal:check I/O mapping and network configuration.

Product Brief

AN-X-AMX4 is ProSoft AN-X series protocol gateway,bridge EtherNet/IP network and Reliance AutoMax legacy DCSNet / Remote I/O racks,for old industrial automation system maintenance and transformation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and renovation.
