ProSoft AN-X-PB2 EtherNet/IP to PROFIBUS DP Multi-Slave Gateway

Technical Specifications

Model:AN-X-PB2

Brand:ProSoft

Product type:Protocol Communication Gateway

Power supply:18-32VDC

Communication:EtherNet/IP, PROFIBUS DP

Weight:0.35kg

Operating temperature:0℃ ~ +50℃

Dimension:107mm126mm34mm

Certification:CE,UL

System compatibility

AN-X-PB2 belongs to ProSoft AN-X series DIN rail gateway.It connects modern EtherNet/IP control network with PROFIBUS DP field devices,suitable for legacy PROFIBUS automation system upgrade and spare replacement.

Function

It works as PROFIBUS DP multi-slave device,realizes bidirectional real-time I/O data mapping between EtherNet/IP controller and PROFIBUS DP master network,supports PROFIBUS network packet capture and analysis for troubleshooting.

Installation

DIN rail mounting,connect 24VDC power,wire Ethernet and PROFIBUS DP bus,configure station parameters and data mapping via web configuration page,check LED indicators.

Interface

110/100Mbps Ethernet RJ45 port,1DB9 PROFIBUS DP connector,power terminal,run and fault status LED indicators.

Feature

Compact DIN rail housing,supports PROFIBUS baud rate from 9600bps up to 12Mbps,firmware upgradable over Ethernet,network capture function without interrupting production bus.

Diagnostic

Check power,link and fault LED;communication failure:verify network cable,bus wiring,terminal resistor,station address and baud rate;data abnormal:check I/O mapping and web configuration.

Product Brief

AN-X-PB2 is ProSoft AN-X series protocol gateway,bridge EtherNet/IP network and PROFIBUS DP field bus,for old industrial automation system maintenance and transformation.
