ProSoft PLX82-MNET-61850 Modbus TCP to IEC 61850 Gateway

Technical Specifications

Model:PLX82-MNET-61850

Brand:ProSoft

Product type:Modbus TCP Client/Server to IEC 61850 Client Standalone Dual Ethernet Communication Gateway

Power supply:10~36VDC,nominal 24VDC,max 500mA@24VDC

Ethernet interface:210/100Mbps RJ45,two physically isolated independent subnets

IEC61850:Client mode,support IEC61850 Ed.2,connect up to 20 IED devices

Supported IEC61850 service:MMS,BRCB buffered report,URCB unbuffered report,GOOSE

Modbus TCP:Support Client and Server mode,max 10 client connections,up to 2000 commands

Weight:0.52kg

Operating temperature:0℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Dimension:140.2mm52.3mm*111mm

Certification:CE,UL,Class I Division2,RoHS,NERC compliant

System compatibility

PLX82-MNET-61850 belongs to ProSoft PLX82 series power substation protocol gateway.

Realize data interconnection between Modbus TCP PLC/SCADA and IEC61850 substation IED intelligent electronic devices.

Compatible with Modbus TCP controllers,Schneider Unity Pro PAC,various brand protection relays and bay controllers.

Suitable for power substation renovation,hydropower station,wind farm,energy management system integration and spare replacement.

Function

Bidirectional protocol conversion between Modbus TCP and IEC 61850 MMS/GOOSE.

Dual independent Ethernet ports,Modbus network and IEC61850 substation network run on separated subnets for network isolation.

Act as IEC61850 client to read report data,control data and receive GOOSE event messages from substation IEDs.

Support import SCL ICD files,map IED data attributes directly to Modbus holding registers automatically.

Support buffered and unbuffered report blocks for periodic and event-driven data transmission.

Built-in NTP time synchronization to guarantee unified time stamp in substation system.

Web page status view,event log and communication diagnostic function.

Optional SD card for configuration backup,clone and fast device replacement.

Configuration via ProSoft 61850 Configuration Manager software.

Installation

Mount gateway on DIN rail,connect 10~36VDC power supply and earth terminal.

Connect one RJ45 port to Modbus TCP control network,another port to IEC61850 substation network.

Import IED SCL ICD files in configuration manager,configure data mapping and GOOSE subscription.

Set Modbus register mapping,read/write permission and polling parameters.

Download project to gateway,verify register mapping.

Check LED indicators after power-on.

Interface

2*10/100Mbps Ethernet RJ45,SD card slot,power terminal,reset button,LED indicators:PWR,RUN,NET1,NET2,ERR.

Feature

Industrial aluminum DIN rail housing,designed for power substation harsh environment.

Dual physically isolated Ethernet ports,separate OT control network and substation network,improve cybersecurity.

SCL file import function,reduce manual configuration workload and avoid human error.

Native GOOSE subscription,support fast substation alarm and trip event transmission.

Dual Modbus client/server mode,support multi-host SCADA access simultaneously.

Built-in event log to record IED communication fault and alarm events.

SD card configuration backup for rapid on-site recovery.

Shock and vibration resistant design,stable long-term operation in substation control cabinet.

Diagnostic

Check PWR and network LED;communication failure:verify IP subnet,SCL file and IED network access;data abnormal:check report control block,GOOSE subscription and Modbus register mapping configuration.

Product Brief

PLX82-MNET-61850 is ProSoft PLX82 series power dedicated protocol gateway.

It bridges Modbus TCP control system and IEC61850 substation IED relays,supports MMS reporting and GOOSE messaging,widely used for power substation automation system transformation.
